Tractor · 1992Unverified
Ford 8430
Ford 8430 — 30 Superforça Series · 140 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
140 hp
Hover a source tag to verify
Overview
ManufacturerFord (a part of New Holland)Reference
Built in Curitiba, BrazilReference
The Brazillian-built Ford 8430 is similar to the Fiat 140-90.Reference
Four-wheel driveReference
Power steeringReference
Hydraulic wet disc brakesReference
Two-post ROPS. Cab optional with air-conditioning.Reference
Engine
Fiat 5.8L 6-cyl dieselReference
Engine104.4 kWReference
Fiat 8065.25Reference
turbocharged dieselReference
6-cylinderReference
liquid-cooledReference
Displacement5.8 LReference
Bore/Stroke104 x 115 mmReference
Power104.4 kWReference
Rated RPM2500Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speed partially synchronizedReference
24-speed creeperReference
Typepartially synchronizedReference
Gears12 forward and 4 reverseReference
Clutch305mm cerametallic discReference
Four gears (1-4) in three ranges (I, II, III) plus reverse (R) range.Reference
TypecreeperReference
Gears24 forward and 8 reverseReference
Four gears (1-4) in three ranges (I, II, III) plus reverse (R) range with additional dual range shift (creeper/normal).Reference
PTO & Hydraulics
Rear TypeIIReference
Controlposition and draft controlReference
Rear PTOindependentReference
ClutchhydraulicReference
Rear PTO Type540/1000 (1.375)Reference
Electrical
Charging systemalternatorReference
Battery volts12Reference
Speeds
With 18.4x38 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
