Tractor · 1958Unverified
Ford 941
Ford 941 — 901 Powermaster Series · 63 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
63 hp
Weight
1496 kg
Hover a source tag to verify
Overview
ManufacturerFordReference
Row-Crop tractorReference
Built in Highland Park, Michigan, USAReference
The Ford 941 Powermaster was the only model in the row-crop 901 series to have the four-speed transmission.Reference
Two-wheel driveReference
Steeringpower assistReference
Differential mechanical expanding shoe brakesReference
Open operator station.Reference
Variants
841utility chassisReference
941four-speedReference
951five-speedReference
961five-speed, live PTOReference
971Select-O-SpeedReference
981Select-O-Speed, dual-speed PTOReference
Engine
Ford 2.8L 4-cyl gasolineReference
Ford 2.8L 4-cyl LP gasReference
Ford 2.8L 4-cyl dieselReference
Engine46.7 kWReference
Belt (claimed)29.8 kWReference
Plows3 (14-inch)Reference
Ford EAFReference
gasolineReference
4-cylinder 8-valveReference
liquid-cooled vertical overhead valveReference
Displacement2.8 LReference
Bore/Stroke99 x 91 mmReference
Power46.7 kWReference
Air cleaneroil bathReference
Compression7.5:1Reference
Rated RPM2000Reference
Torque225.1 NmReference
Torque RPM1600Reference
Firing order1-2-4-3Reference
Starter volts6Reference
Coolant capacity14.2 LReference
Sparkplug gap0.686 mmReference
Point gap0.635 mmReference
Intake valve clearance0.381 mmReference
Exhaust valve clearance0.381 mmReference
Oil capacity4.7 LReference
Oil change100 hReference
LP gasReference
liquid-cooledReference
Compression8.65:1Reference
Rated RPM2200Reference
FordReference
dieselReference
Power42.0 kWReference
Compression16.8:1Reference
Torque190.4 NmReference
Torque RPM1400Reference
Starter volts12Reference
Transmission
4-speed unsynchronized gearReference
ManufacturerFordReference
Typeunsynchronized gearReference
Gears4 forward and 1 reverseReference
Oil capacity5.7 LReference
Oil typeSAE 80Reference
Capacities
Fuel64.3 LReference
PTO & Hydraulics
Hydraulic system7.6 LReference
Typeopen centerReference
Capacity7.6 LReference
Pressure137.9 barReference
Total flow15.1 lpmReference
Rear TypeIReference
Rear lift567 kgReference
Rear PTOtransmissionReference
Rear PTO Type540Reference
Dimensions
Weight1496 kgReference
Front tire5.50-16Reference
Rear tire12-28Reference
Ag front5.50-16Reference
Ag rear12-28Reference
Length336 cmReference
Height167 cmReference
Ground clearance70 cmReference
Front tread21 to 41 cmReference
Rear tread142 to 203 cmReference
Ford 941 attachments
front-end loaderReference
941 Serial Number Location
Left side of tractor, on top of transmission case behind the starter.Reference
941 Serial Numbers
19571001Reference
195811977Reference
195958312Reference
1960105943Reference
1961131427Reference
1962155531Reference
FAQ: How to read a serial number table.Reference
Electrical
Groundpositive (6V)Reference
Groundnegative (12V)Reference
Charging systemgeneratorReference
Charging amps20Reference
Battery volts6 (gas/lp)Reference
Battery volts12 (diesel)Reference
Battery AH80 (6V)Reference
Battery AH135 (12V)Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
