Tractor · 1977Unverified
Ford 9700
Ford 9700 — Row-Crop tractor · 136 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
136 hp
Max power
84.5 kW
Weight
10900 to 12860 pounds
Hover a source tag to verify
Overview
ManufacturerFordReference
Row-Crop tractorReference
FactoriesRomeo, Michigan, USAReference
FactoriesAntwerp, BelgiumReference
Original price$22,700Reference
Two- or four-wheel driveReference
Final drivesinboard planetaryReference
Differential lockmechanical rearReference
Power steeringReference
Hydraulic wet disc brakesReference
Open operator station. Cab optional with air-conditioning.Reference
Engine
Ford 6.6L 6-cyl dieselReference
Fuel tank219.5 LReference
Engine108.9 kWReference
Drawbar (tested)84.5 kWReference
FordReference
turbocharged dieselReference
6-cylinderReference
liquid-cooledReference
Displacement6.6 LReference
Bore/Stroke112 x 112 mmReference
Power108.9 kWReference
Air cleanerdual dry elementReference
Pre-heatingether injectionReference
Compression15.6:1Reference
Rated RPM2200Reference
Starter volts12Reference
Oil capacity13.2 LReference
Coolant capacity20.8 LReference
Coolant capacity22.2 LReference
Power at rated engine speed101.1 kWReference
Max power84.5 kWReference
Transmission
8-speed gearReference
16-speed two-speed power shiftReference
TypegearReference
Gears8 forward and 2 reverseReference
Clutchdry discReference
Four gears, plus reverse, in two ranges.Reference
TransmissionDual PowerReference
Typetwo-speed power shiftReference
Gears16 forward and 4 reverseReference
PTO & Hydraulics
PTO (claimed)100.7 kWReference
PTO (tested)101.1 kWReference
Typeopen centerReference
Pump flow58.7 lpmReference
Steering flow15.9 lpmReference
Rear TypeIIIReference
Rear lift2614 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Engine RPM540@1900Reference
Engine RPM1000@1935Reference
Power at rated PTO speed96.4 kWReference
Dimensions
Wheelbase237 cmReference
Wheelbase278 cmReference
Wheelbase281 cmReference
Weight10900 to 12860 poundsReference
Front tire10.00-16Reference
Rear tire18.4-38Reference
Standard tires (ag)Front: 10.00-16. Rear: 18.4-38Reference
4WD Standard tires (ag)Front: 13-24. Rear: 15-38Reference
Ag front11.00-16Reference
Length457 cmReference
Width201 cmReference
Front tread142 to 213 cmReference
Rear tread152 to 223 cmReference
Shipping4944 kgReference
Operating5833 kgReference
Ballasted7928 kgReference
9700 Serial Numbers
1976C490300Reference
1977C527300Reference
1978C560500Reference
1979C595800Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Battery volts12Reference
Ford 9700 Height
Hood203 cmReference
Cab302 cmReference
Exhaust323 cmReference
Test results
Diesel 16-speed 2WDMay 9 - 20, 1977Link: Nebraska Tractor Test 1243 fileReference
PTO performanceReference
Fuel use34.4 l/hourReference
Fuel use30.7 l/hourReference
Drawbar performanceReference
Fuel use34.1 l/hourReference
Gear 5PD used for power test.Reference
Max pull6808 kgReference
Speeds
With 15-38 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
