Tractor · 1989Unverified

Ford 976

Name: Ford 976
Brand: Ford

Ford 976 — 900 Series · 316 hp. Reference specifications; pending source verification.

The Ford 976 is a tractor with a rated power of 316 hp, classifying it as a powerful model within its category. It was produced from 1989 to 1993. The tractor features a 6-cylinder turbocharged diesel liquid-cooled engine, paired with four-wheel drive and a powershift transmission. It has an operating weight of 9570 kg, making it suitable for large-scale operations covering 1,500+ acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

316 hp

Weight

9570 kg

Catalogue coverage

Variants represented

Richest spec table

97 rows

Recorded power

316 hp

Recorded weight

9570 kg

Transmissions

12-speed constant mesh

Production years

1989-1993

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerFordReference

Four-wheel Drive (4WD) tractorReference

Built in Winnipeg, Manitoba, CanadaReference

Original price was $113,500 in 1993Reference

Four-wheel driveReference

Final drivesoutboard planetaryReference

Articulated power steeringReference

Hydraulic disc brakesReference

Cab standard with air-conditioning.Reference

Engine

Cummins 14.0L 6-cyl dieselReference

Engine268.5 kWReference

Drawbar (claimed)216.3 kWReference

Cummins NTA-855-A360Reference

aftercooled turbocharged dieselReference

6-cylinderReference

liquid-cooled inlineReference

Displacement14.0 LReference

Bore/Stroke140 x 152 mmReference

Power268.5 kWReference

Air cleanerdual dry elementReference

Pre-heatingether injectionReference

Pre-heatingblock heaterReference

Rated RPM2100Reference

Idle RPM1000-2100Reference

Torque1586.5 NmReference

Torque RPM1400Reference

Starter volts12Reference

Oil capacity37.0 LReference

Coolant capacity60.3 LReference

Transmission

12-speed constant meshReference

12-speed full power shiftReference

ManufacturerVersatileReference

Typeconstant meshReference

Gears12 forward and 4 reverseReference

Clutch394mm dry discReference

Oil capacity20.3 LReference

Four gears in three ranges, plus reverse range.Reference

Typefull power shiftReference

Gears12 forward and 2 reverseReference

Clutch228mm wet discReference

Oil capacity47.3 LReference

PTO & Hydraulics

PTO (claimed)235.6 kWReference

Hydraulic system57.9 LReference

Typeclosed center load sensingReference

Capacity57.9 LReference

Pressure165.5 barReference

Valves4 to 5Reference

Pump flow92.7 lpmReference

Steering flow98.8 lpmReference

Steering press.158.6 barReference

Rear TypeIVN/IIIReference

Controlposition controlReference

Rear lift (at 24"/610mm)5913 kgReference

Rear PTOindependentReference

Rear PTO Type1000 (1.75)Reference

Capacities

Fuel1082.5 LReference

Dimensions

Wheelbase330 cmReference

Weight9570 kgReference

Front tire24.5-32Reference

Rear tire24.5-32Reference

Ag front24.5-32Reference

Ag rear24.5-32Reference

Ag front18.4x38Reference

Ag front18.4x42Reference

Ag front20.8x38Reference

Ag front20.8x42Reference

Ag front30.5x32Reference

Ag rear18.4x38Reference

Ag rear18.4x42Reference

Ag rear20.8x38Reference

Ag rear20.8x42Reference

Ag rear30.5x32Reference

Length660 cmReference

Shipping weight9570 kgReference

Max weight16329 kgReference

Ground clearance40 cmReference

Steering wheel260 cmReference

976 Serial Numbers

Location:Serial number plate on the cab door post.Reference

1985976 85 234050Reference

1986976 86 270102Reference

1987976 87 ------Reference

1988976 88 330140Reference

1989976 89 D430100Reference

1990976 90 D450100Reference

1991976 91 D475198Reference

1992976 92 D485039Reference

1993976 93 D930055Reference

Final976 93 D931144Reference

FAQ: How to read a serial number table.Reference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps90Reference

Batteries4Reference

Battery CCA625Reference

Battery volts12Reference

Ford 976 Height

Cab317 cmReference

Exhaust332 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
