Lawn Tractor · 1992Unverified
Ford GT-65
Ford GT-65 — GT Series · 14 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
14 hp
Weight
476 kg
Hover a source tag to verify
Overview
DistributorFordReference
ManufacturerShibauraReference
Garden tractorReference
Two-wheel driveReference
SteeringmanualReference
SteeringpowerReference
Disc brakesReference
Open operator station.Reference
Engine
14HP Shibaura 617cc 3-cyl dieselReference
Fuel tank15.9 LReference
Shibaura E643Reference
dieselReference
3-cylinderReference
liquid-cooled horizontal-shaft inlineReference
Displacement37.7 ciReference
Bore/Stroke64 x 64 mmReference
Power (gross)10.4 kWReference
Air cleanerdryReference
Pre-heatingglow plugsReference
Pre-heatingblock heaterReference
Compression23:1Reference
Rated RPM3200Reference
Idle RPM1400-3450Reference
Firing order1-2-3Reference
Starter volts12Reference
Oil capacity3.0 LReference
Coolant capacity3.3 LReference
Transmission
hydrostaticReference
Typeshaft-driven hydrostaticReference
Gearsinfinite forward and reverse (2-range)Reference
Oil capacity8.6 LReference
Oil capacity9.6 LReference
PTO & Hydraulics
Rear Type0Reference
Rear PTOoptionalReference
Mid PTOindependentReference
Clutchmanual idler pulleyReference
Front PTOindependentReference
Dimensions
Wheelbase126 cmReference
Weight476 kgReference
Front tire16x6.50-8Reference
Rear tire23x10.50-12Reference
Lawn/turf front16x6.50-8Reference
Lawn/turf rear23x10.50-12Reference
Length189 cmReference
Width99 cmReference
Height (steering wheel)114 cmReference
Shipping weight476 kgReference
Ground clearance15 cmReference
Ford GT-65 attachments
44" mid-mount mower deckReference
48" mid-mount mower deckReference
60" mid-mount mower deckReference
snowblowerReference
bladeReference
GT-65 Serial Number Location
Serial number plate on the left side of the tractor frame, above the front axle.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery CCA332Reference
Battery volts12Reference
Attachment overview
44" mid-mount mower deckReference
48" mid-mount mower deckReference
60" mid-mount mower deckReference
SnowblowerReference
BladeReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
