Lawn Tractor · 1994Unverified
Ford LS35 9861898
Ford LS35 9861898 — LS Series · 15 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
15 hp
Weight
231 kg
Hover a source tag to verify
Overview
DistributorFordReference
ManufacturerToroReference
Garden tractorReference
Two-wheel driveReference
Manual steeringReference
Mechanical band brakesReference
Open operator station with adjustable seat.Reference
Variants
264similar Wheel Horse modelReference
Engine
15HP Kohler 426cc 1-cyl gasolineReference
Fuel tank14.8 LReference
Kohler CV14Reference
gasolineReference
1-cylinderReference
air-cooled vertical-shaftReference
Displacement26 ciReference
Bore/Stroke90 x 67 mmReference
Power (gross)11.2 kWReference
Rated RPM3600Reference
StarterelectricReference
Starter volts12Reference
Oil capacity1.9 LReference
Transmission
hydrostaticReference
TransmissionTuff Torq K61Reference
Typebelt-driven hydrostaticReference
Gearsinfinite forward and reverseReference
Oil capacity3.3 LReference
Foot-pedal controlled hydrostatic transmission with optional cruise control.Reference
PTO & Hydraulics
Mid PTOindependentReference
Clutchelectro-magneticReference
Dimensions
Wheelbase125 cmReference
Weight231 kgReference
Front tire16x6.50-8Reference
Rear tire23x9.50-12Reference
Lawn/turf front16x6.50-8Reference
Lawn/turf rear23x9.50-12Reference
Length175 cmReference
Width89 cmReference
Height (steering wheel)107 cmReference
Ground clearance18 cmReference
Front axleCast-ironReference
Ford LS35 attachments
38" mid-mount mower deckReference
42" mid-mount mower deckReference
snowblowerReference
bladeReference
LS35 Serial Number Location
Serial number decal located on the fender deck under the tractor's seat.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps15Reference
Battery CCA200Reference
Battery volts12Reference
Attachment overview
38" mid-mount mower deckReference
42" mid-mount mower deckReference
SnowblowerReference
BladeReference
Attachments advertised for the Ford LS Series yard tractors included a 36-inch rear tiller, grass catcher for the 38-inch deck, and power-flow bagger for the 42 and inch deck.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
