Lawn Tractor · 1994Unverified
Ford LS45
Ford LS45 — LS Series · 16 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
16 hp
Weight
510 to 521 pounds
Hover a source tag to verify
Overview
DistributorFordReference
ManufacturerToroReference
Garden tractorReference
Two-wheel driveReference
Manual steeringReference
Hydro Brakesmechanical bandReference
Open operator station with adjustable seat.Reference
Variants
9861899gearReference
9861900hydrostaticReference
266-Hsimilar Wheel Horse modelReference
Engine
16HP Kohler 624cc 2-cyl gasolineReference
Fuel tank14.8 LReference
Kohler CV16Reference
gasolineReference
2-cylinderReference
air-cooled vertical-shaft V-TwinReference
Displacement38.1 ciReference
Bore/Stroke77 x 67 mmReference
Power (gross)11.9 kWReference
Rated RPM3600Reference
StarterelectricReference
Starter volts12Reference
Oil capacity1.9 LReference
Transmission
hydrostaticReference
6-speed gearReference
Gear BrakesdeckReference
Gear Weight231 kgReference
Gear Ground clearance20 cmReference
TransmissionTuff Torq K61Reference
Typebelt-driven hydrostaticReference
Gearsinfinite forward and reverseReference
Oil capacity3.3 LReference
Foot-pedal controlled hydrostatic transmission with optional cruise control.Reference
TransmissionPeerlessReference
TypegearReference
Gears6 forward and 1 reverseReference
The gear-drive LS45 was produced from 1994 to 1996, only the hydrostatic was available after that time.Reference
PTO & Hydraulics
Mid PTOindependentReference
Clutchelectro-magneticReference
Dimensions
Wheelbase125 cmReference
Weight510 to 521 poundsReference
Front tire16x6.50-8Reference
Rear tire23x10.50-12Reference
Lawn/turf front16x6.50-8Reference
Lawn/turf rear23x10.50-12Reference
Length175 cmReference
Width89 cmReference
Height (steering wheel)107 cmReference
Hydro Weight236 kgReference
Hydro Ground clearance18 cmReference
Front axleCast-ironReference
Ford LS45 attachments
38" mid-mount mower deckReference
42" mid-mount mower deckReference
48" mid-mount mower deckReference
snowblowerReference
bladeReference
LS45 Serial Number Location
Serial number decal located on the fender deck under the tractor's seat.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps15Reference
Battery CCA280Reference
Battery volts12Reference
Attachment overview
38" mid-mount mower deckReference
42" mid-mount mower deckReference
48" mid-mount mower deckReference
SnowblowerReference
BladeReference
Attachments advertised for the Ford LS Series yard tractors included a 36-inch rear tiller, grass catcher for the 38-inch deck, and power-flow bagger for the 42 and 48 inch decks.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
