Lawn Tractor · 1994Unverified
Ford LS55
Ford LS55 — LS Series · 18 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
18 hp
Weight
231 kg
Hover a source tag to verify
Overview
DistributorFordReference
ManufacturerToroReference
Garden tractorReference
The Ford LS55 is similar to the Toro/Wheelhorse 269-H.Reference
Two-wheel driveReference
Manual steeringReference
Mechanical band brakesReference
Open operator station with adjustable seat.Reference
Variants
9861901without cruise controlReference
9862543with cruise controlReference
268-Hsimilar Wheel Horse modelReference
Engine
18HP Kohler 624cc 2-cyl gasolineReference
Fuel tank14.8 LReference
Kohler CV18Reference
gasolineReference
2-cylinderReference
air-cooled vertical-shaft V-TwinReference
Displacement38.1 ciReference
Bore/Stroke77 x 67 mmReference
Power (gross)13.4 kWReference
Rated RPM3600Reference
StarterelectricReference
Starter volts12Reference
Oil capacity1.9 LReference
Transmission
hydrostaticReference
TransmissionTuff Torq K61Reference
Typebelt-driven hydrostaticReference
Gearsinfinite forward and reverseReference
Oil capacity3.3 LReference
Foot-pedal controlled hydrostatic transmission with cruise control standard.Reference
PTO & Hydraulics
Mid PTOindependentReference
Clutchelectro-magneticReference
Dimensions
Wheelbase125 cmReference
Weight231 kgReference
Front tire16x6.50-8Reference
Rear tire23x10.50-12Reference
Lawn/turf front16x6.50-8Reference
Lawn/turf rear23x10.50-12Reference
Length175 cmReference
Width89 cmReference
Height (steering wheel)107 cmReference
Ground clearance18 cmReference
Front axleCast-ironReference
Ford LS55 attachments
38" mid-mount mower deckReference
42" mid-mount mower deckReference
48" mid-mount mower deckReference
snowblowerReference
bladeReference
LS55 Serial Number Location
Serial number decal located on the fender deck under the tractor's seat.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps15Reference
Battery CCA280Reference
Battery volts12Reference
Attachment overview
38" mid-mount mower deckReference
42" mid-mount mower deckReference
48" mid-mount mower deckReference
SnowblowerReference
BladeReference
Attachments advertised for the Ford LS Series yard tractors included a 36-inch rear tiller, grass catcher for the 38-inch deck, and power-flow bagger for the 42 and 48 inch decks.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
