Lawn Tractor · 1990Unverified

Ford LT-10

Name: Ford LT-10
Brand: Ford

Ford LT-10 — Lawn tractor · 10 hp. Reference specifications; pending source verification.

The Ford LT-10 is a lawn tractor model with a rated power output of 10 hp, positioning it at the lower end of its class. It was manufactured in 1990. It features a 1-cylinder petrol air-cooled engine, paired with two-wheel drive and a 4-speed gearbox. The tractor has an operating weight of 222 kg and is suited to operations on areas of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

10 hp

Weight

222 kg

Catalogue coverage

Variants represented

Richest spec table

44 rows

Recorded power

10 hp

Recorded weight

222 kg

Transmissions

4-speed gear

Production years

1990-1990

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerFordReference

Lawn tractorReference

Two-wheel driveReference

Manual steeringReference

Mechanical disc brakesReference

Open operator station.Reference

Engine

10HP Briggs & Stratton 399cc 1-cyl gasolineReference

Fuel tank3.8 LReference

Briggs & Stratton 191707Reference

gasolineReference

1-cylinderReference

air-cooledReference

Displacement24.36 ciReference

Bore/Stroke87 x 67 mmReference

Power7.5 kWReference

Air cleanerdual elementReference

StarterelectricReference

Starter volts12Reference

Oil capacity1.0 LReference

Transmission

4-speed gearReference

Typebelt-driven gearReference

Gears4 forward and 1 reverseReference

Oil capacity1.0 LReference

Dimensions

Wheelbase124 cmReference

Weight222 kgReference

Front tire15x6.00-6Reference

Rear tire18x8.50-8Reference

Lawn/turf front15x6.00-6Reference

Lawn/turf rear18x8.50-8Reference

Length175 cmReference

Height (steering wheel)101 cmReference

Ground clearance15 cmReference

Ford LT-10 attachments

38" mid-mount mower deckReference

snowblowerReference

Electrical

GroundnegativeReference

Charging amps3Reference

Battery volts12Reference

Attachment overview

38" mid-mount mower deckReference

SnowblowerReference

38" Mower deck

Typemid-mount FordReference

Typemanual liftReference

Cutting width96 cmReference

Overall width119 cmReference

Cut height4 to 9 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
