Lawn Tractor · 1992Unverified
Ford LT-12.5A
Ford LT-12.5A — LT-A Series · 13 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
13 hp
Weight
249 kg
Hover a source tag to verify
Overview
DistributorFordReference
ManufacturerLawn-BoyReference
Lawn tractorReference
Two-wheel driveReference
Manual steeringReference
Mechanical disc brakesReference
Open operator station.Reference
Variants
LT-12.5gearReference
LT12-5AhydrostaticReference
Engine
12.5HP Briggs & Stratton 465cc 1-cyl gasolineReference
Fuel tank7.6 LReference
Briggs & Stratton 285000Reference
gasolineReference
1-cylinderReference
air-cooled vertical-shaftReference
Displacement28.4 ciReference
Bore/Stroke87 x 78 mmReference
Power (gross)9.3 kWReference
StarterelectricReference
Starter volts12Reference
Oil capacity1.4 LReference
Transmission
5-speed gearReference
Typebelt-driven gearReference
Gears5 forward and 1 reverseReference
PTO & Hydraulics
Mid PTOindependentReference
ClutchelectricReference
Mid PTO TypepulleyReference
Dimensions
Wheelbase124 cmReference
Weight249 kgReference
Front tire15x6.00-6Reference
Rear tire20x10.00-8Reference
Lawn/turf front15x6.00-6Reference
Lawn/turf rear20x10.00-8Reference
Length175 cmReference
Height (steering wheel)101 cmReference
Shipping weight249 kgReference
Ground clearance15 cmReference
Ford LT-12.5A attachments
38" mid-mount mower deckReference
snowblowerReference
bladeReference
LT-12.5A Serial Numbers
Location:Serial number tag on the left side of the tractor frame, behind the front axle.Reference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
38" mid-mount mower deckReference
SnowblowerReference
BladeReference
38" Mower deck
Typemid-mount FordReference
Type2-blade with manual liftReference
Cutting width96 cmReference
BeltDA2705019Reference
Overall width119 cmReference
Cut height4 to 9 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
