Tractor · 1992Unverified

Ford-New Holland 4030

Name: Ford-New Holland 4030
Brand: Ford-New Holland

Ford-New Holland 4030 — Orchard/Vineyard tractor · 51 hp. Reference specifications; pending source verification.

The Ford-New Holland 4030 is a compact tractor rated at 51 horsepower, manufactured from 1992 to 1997. It features a 3-cylinder diesel liquid-cooled engine, coupled with a four-wheel drive system and a 12-speed gearbox. The tractor's weight ranges from 4662 to 5069 pounds. It is intended for use on small to medium-sized plots of land, typically up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

51 hp

Weight

4662 to 5069 pounds

Catalogue coverage

Variants represented

Richest spec table

79 rows

Recorded power

51 hp

Recorded weight

2114 kg

Transmissions

12-speed gear

Production years

1992-1997

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

DistributorFord-New HollandReference

ManufacturerFiatReference

Orchard/Vineyard tractorReference

Original price was $23,500 in 1997Reference

Two- or four-wheel driveReference

Final drivesinboard planetaryReference

Differential lockmechanical rearReference

Power steeringReference

Mechanical wet disc brakesReference

Two-post mid-mount ROPS. Cab optional with air-conditioning.Reference

Variants

4030NnarrowReference

Engine

Fiat 2.9L 3-cyl dieselReference

FiatReference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement2.9 LReference

Bore/Stroke104 x 115 mmReference

Pre-heatingthermostartReference

Rated RPM2500Reference

Starter volts12Reference

Transmission

12-speed gearReference

12-speed shuttleReference

TypegearReference

Gears12 forward and 4 reverseReference

TypeshuttleReference

Gears12 forward and reverseReference

PTO & Hydraulics

PTO (claimed)38.0 kWReference

Hydraulic system42.8 LReference

Typeopen centerReference

Capacity42.8 LReference

Pressure188.9 barReference

Valves2 or 3Reference

Pump flow41.6 lpmReference

Steering flow30.7 lpmReference

2WD Steering press.70.0 barReference

4WD Steering press.100.0 barReference

Rear TypeIReference

Controlposition control and lower-link draft sensingReference

Rear lift2225 kgReference

Rear PTOindependentReference

Rear PTO Type540Reference

Capacities

Fuel51.9 LReference

Dimensions

2WD Wheelbase188 cmReference

4WD Wheelbase199 cmReference

Weight4662 to 5069 poundsReference

Front tire27x9.50-15Reference

2WD Rear tire14.9x24Reference

2WD Standard tires (ag)Front: 27x9.50-15. Rear: 14.9x24Reference

4WD Standard tires (ag)Front: 9.5x16. Rear: 14.9x24Reference

2WD Length341 cmReference

4WD Length355 cmReference

2WD Width146 cmReference

4WD Width148 cmReference

2WD Weight2114 kgReference

4WD Weight2299 kgReference

2WD Clearance (front axle)39 cmReference

4WD Clearance (front axle)39 cmReference

2WD Front tread116 to 147 cmReference

4WD Front tread119 to 134 cmReference

Rear tread106 to 144 cmReference

2WD Steering wheel134 cmReference

4WD Steering wheel138 cmReference

4030 Serial Numbers

1992F474600Reference

1993F005600Reference

1994F022000Reference

1995F046874Reference

19961084630Reference

FAQ: How to read a serial number table.Reference

Electrical

GroundnegativeReference

Charging systemalternatorReference

ROPS Charging amps33Reference

Cab Charging amps65Reference

Battery volts12Reference

Ford-New Holland 4030 Height

2WD Hood123 cmReference

4WD Hood127 cmReference

2WD ROPS211 cmReference

4WD ROPS215 cmReference

Speeds

With 14.9-24 rear tires.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
