Tractor · 1985Unverified
Ford-New Holland 8210
Ford-New Holland 8210 — Row-Crop tractor · 115 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
115 hp
Weight
8730 to 9370 pounds
Hover a source tag to verify
Overview
ManufacturerFord-New HollandReference
Row-Crop tractorReference
Original price was $49,000 in 1991Reference
Two- or four-wheel driveReference
Differential lockmechanical rearReference
Power steeringReference
Mechanical wet disc brakesReference
Cab standard with air-conditioning. Optional AM/FM radio.Reference
Engine
Ford 6.6L 6-cyl dieselReference
Fuel tank177.9 LReference
Engine (gross)85.8 kWReference
Engine (net)82.0 kWReference
FordReference
dieselReference
6-cylinderReference
liquid-cooledReference
Displacement6.6 LReference
Bore/Stroke112 x 112 mmReference
Power (net)82.0 kWReference
Power (gross)85.8 kWReference
Air cleanerdual dry elementReference
Pre-heatingthermostartReference
Compression16.3:1Reference
Rated RPM2300Reference
Starter volts12Reference
Oil capacity18.9 LReference
Coolant capacity21.3 LReference
Transmission
16-speed two-speed power shiftReference
TransmissionDual PowerReference
Typetwo-speed power shiftReference
Gears16 forward and 8 reverseReference
Clutch330mm dry discReference
Oil capacity56.8 LReference
PTO & Hydraulics
PTO (claimed)70.8 kWReference
Typeopen centerReference
Valves2 to 4Reference
SCV flow68.9 lpmReference
Rear TypeIIReference
Controlposition control and top-link draft sensingReference
Rear lift (at 24"/610mm)2011 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000 (1.375)Reference
Engine RPM540@1902Reference
Engine RPM1000@2049Reference
Dimensions
Wheelbase278 cmReference
Weight8730 to 9370 poundsReference
Front tire14.9-24Reference
Rear tire18.4-34Reference
Ag front14.9-24Reference
Ag rear18.4-34Reference
Ag front14.9-28Reference
Ag rear18.4-38Reference
Ag rear16.9-38Reference
Length448 cmReference
2WD Weight3959 kgReference
4WD Weight4250 kgReference
Clearance (front axle)49 cmReference
Front tread152 to 200 cmReference
Rear tread152 to 203 cmReference
Steering wheel219 cmReference
Ford-New Holland 8210 attachments
front-end loaderReference
8210 Serial Numbers
Location:Data plate inside engine compartment.Reference
1982C681910Reference
1983C695880Reference
1984C713459Reference
1985C737800Reference
1986C754100Reference
1987C768000Reference
1988BB06622Reference
1989BB80260Reference
1990BC26239Reference
1991BC68791Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps72Reference
Battery volts12Reference
Battery AH128Reference
Ford-New Holland 8210 Height
Cab289 cmReference
Exhaust303 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
