Lawn Tractor · 1988Unverified
Ford R-12
Ford R-12 — Riding lawn mower · 12 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
12 hp
Weight
204 kg
Hover a source tag to verify
Overview
DistributorFordReference
ManufacturerGilsonReference
Riding lawn mowerReference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Engine
12HP Briggs & Stratton 465cc 1-cyl gasolineReference
Fuel tank2.8 LReference
Briggs & Stratton 285000Reference
gasolineReference
1-cylinderReference
air-cooled vertical-shaftReference
Displacement28.4 ciReference
Bore/Stroke87 x 78 mmReference
Power (gross)8.9 kWReference
Air cleanerdryReference
StarterelectricReference
Starter volts12Reference
Oil capacity0.7 LReference
Transmission
5-speed gearReference
TypegearReference
Gears5 forward and 1 reverseReference
PTO & Hydraulics
Mid PTOindependentReference
Mid PTO TypepulleyReference
Dimensions
Wheelbase111 cmReference
Weight204 kgReference
Front tire4.10/3.50x4Reference
Rear tire16x7.50-8Reference
Lawn/turf front4.10/3.50x4Reference
Lawn/turf rear16x7.50-8Reference
Length158 cmReference
Width111 cmReference
Height (steering wheel)95 cmReference
Shipping weight204 kgReference
Ford R-12 attachments
30" mid-mount mower deckReference
Electrical
GroundnegativeReference
Battery volts12Reference
30" Mower deck
Typemid-mount FordReference
Type1-bladeReference
Cutting width76 cmReference
Cut height3 to 8 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
