Tractor · 1983Unverified
Ford TW-15
Ford TW-15 — TW Series · 140 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
140 hp
Max power
79.0 kW
Weight
11355 to 14300 pounds
Hover a source tag to verify
Overview
ManufacturerFordReference
Row-Crop tractorReference
Built in Antwerp, BelgiumReference
Original price$41,000Reference
Two- or four-wheel driveReference
Differential lockhydraulic rearReference
Power steeringReference
Differential hydraulic wet disc brakesReference
Two-post fixed ROPS. Cab optional with air-conditioning.Reference
Engine
Ford 6.6L 6-cyl dieselReference
Engine (gross)104.4 kWReference
Engine102.2 kWReference
Drawbar (tested)79.0 kWReference
FordReference
turbocharged dieselReference
6-cylinderReference
liquid-cooledReference
Displacement6.6 LReference
Bore/Stroke112 x 112 mmReference
Power102.2 kWReference
Power (gross)104.4 kWReference
Air cleanerdryReference
Compression15.6:1Reference
Rated RPM2200Reference
Idle RPM700-2470Reference
Torque520.7 NmReference
Torque RPM1600Reference
Firing order1-5-3-6-2-4Reference
Starter volts12Reference
Oil capacity18.9 LReference
Coolant capacity20.8 LReference
Power at rated engine speed90.5 kWReference
Max power79.0 kWReference
Power at rated engine speed90.4 kWReference
Max power78.9 kWReference
Transmission
16-speed two-speed power shiftReference
24-speedReference
TransmissionDual PowerReference
Typetwo-speed power shiftReference
Gears16 forward and 4 reverseReference
Clutch356mm dry discReference
Oil capacity87.1 LReference
Electrically-actuated Dual Power allows shift-on-the-move from Direct mode to lower Power Mode for each gear.Reference
Gears24 forward and 6 reverseReference
PTO & Hydraulics
PTO (claimed)89.5 kWReference
PTO (tested)90.5 kWReference
Hydraulic system69.1 LReference
Hydraulic system90.1 LReference
Typeopen centerReference
Capacity69.1 LReference
Capacity90.1 LReference
Pressure172.4 barReference
Valves2Reference
Pump flow57.9 lpmReference
Total flow104.1 lpmReference
Steering flow15.9 lpmReference
Rear TypeII/IReference
Rear TypeIIIReference
Rear lift (at 24"/610mm)3243 kgReference
Rear lift (at 24"/610mm)4286 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Engine RPM540@1861Reference
Engine RPM1000@1918Reference
Power at rated PTO speed87.9 kWReference
Power at rated PTO speed86.2 kWReference
Capacities
Fuel219.5 LReference
Dimensions
2WD Wheelbase274 cmReference
4WD Wheelbase266 cmReference
Weight11355 to 14300 poundsReference
Front tire10.00-16Reference
Rear tire18.4-38Reference
Ag front10.00-16 (2WD)Reference
Ag rear18.4-38Reference
Ag front11.00-16 (2WD)Reference
Ag front14L-16 (2WD)Reference
Ag front14.9-24 (4WD)Reference
Ag front14.9-28 (4WD)Reference
Ag front16.9-28 (4WD)Reference
Ag rear20.8-38Reference
Length414 cmReference
Width212 cmReference
Ground clearance41 cmReference
2WD Front tread152 to 213 cmReference
4WD Front tread165 to 213 cmReference
Rear tread162 to 279 cmReference
Rear tread162 to 294 cmReference
ROPS Shipping5150 kgReference
Operating6486 kgReference
Ballasted7566 kgReference
Steering wheel246 cmReference
Ford TW-15 attachments
front-end loaderReference
TW-15 Serial Numbers
Location:Under forward right grill panelReference
1983C694500Reference
1984C707400Reference
1985C732600Reference
1986A915854Reference
1987A917560Reference
1988A919438Reference
1989A922535Reference
1990A925099Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps72Reference
Battery volts12Reference
Battery AH128Reference
Attachment overview
Ford 773 loaderReference
Ford 7412 loaderReference
Ford TW-15 Height
ROPS287 cmReference
Cab294 cmReference
Exhaust331 cmReference
Test results
NTTL 1515: diesel 16-speed 2WDReference
NTTL 1536: diesel 16-speed 4WDReference
Diesel 16-speed 2WDApril 25 - May 12, 1984Link: Nebraska Tractor Test 1515 fileReference
PTO performanceReference
Fuel use29.1 l/hourReference
Fuel use26.5 l/hourReference
Drawbar performanceReference
Gear 5L used for power test.Reference
Max pull6008 kgReference
Gear 2L used for pull test.Reference
Diesel 16-speed 4WDSeptember 10 - 18, 1984Link: Nebraska Tractor Test 1536 fileReference
Fuel use28.8 l/hourReference
Fuel use3.8 l/hourReference
Max pull7229 kgReference
Gear 1H used for pull test.Reference
Speeds
With 18.4x38 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
