Tractor · 1929Unverified
Fordson Fordson N
Fordson Fordson N — Standard-tread tractor · 26 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
26 hp
Max power
10.1 kW
Weight
1632 kg
Hover a source tag to verify
Overview
ManufacturerFordson (a part of Ford)Reference
Standard-tread tractorReference
FactoriesCork, IrelandReference
FactoriesDagenham, EnglandReference
Original priceGPB156 (1935 steel )Reference
Original priceGBP245 (1935 rubber )Reference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Engine
Ford 4.4L 4-cyl keroseneReference
Ford 4.4L 4-cyl gasolineReference
Engine19.4 kWReference
Drawbar (claimed)11.2 kWReference
Plows2Reference
Drawbar (tested)13.6 kWReference
Belt (tested)21.7 kWReference
FordReference
keroseneReference
4-cylinderReference
liquid-cooledReference
Displacement4.4 LReference
Bore/Stroke105 x 127 mmReference
Power15.7 kWReference
Rated RPM1100Reference
Firing order1-2-4-3Reference
Starter typehand-crankReference
gasolineReference
Power19.4 kWReference
Fuel systemZenith IN5F carburetorReference
Belt power (max)17.3 kWReference
Max power10.1 kWReference
Belt power (max)21.7 kWReference
Max power13.6 kWReference
Transmission
3-speed gearReference
TypegearReference
Gears3 forward and 1 reverseReference
Dimensions
Wheelbase160 cmReference
Weight1632 kgReference
Rear tire42x12Reference
Ag rear42x12 steelReference
Length259 cmReference
Width160 cmReference
Height139 cmReference
Fordson N Serial Numbers
Location:Serial number below the cylinder head on the right side of the engine.Reference
1929747682Reference
1930757369Reference
1931772565Reference
1932776066Reference
1933779154Reference
1934781967Reference
1935785548Reference
1936794703Reference
1937807581Reference
1938826779Reference
1939837826Reference
1940854238Reference
1941874914Reference
1942897624Reference
1943925274Reference
1944957574Reference
1945975419Reference
FAQ: How to read a serial number table.Reference
Electrical
Charging systemBosch magnetoReference
Test results
NTTL 173: kerosene 3-speed 2WDReference
NTTL 174: gasoline 3-speed 2WDReference
Kerosene 3-speed 2WDMarch 11 - April 8, 1930Link: Nebraska Tractor Test 173 fileReference
Belt fuel use (max)12.5 l/hourReference
Drawbar performanceReference
Gear 1 used for power test.Reference
Max pull1491 kgReference
Gear 1 used for pull test.Reference
Gasoline 3-speed 2WDMarch 20 - April 10, 1930Link: Nebraska Tractor Test 174 fileReference
Belt fuel use (max)11.7 l/hourReference
Gear 2 used for power test.Reference
Max pull1452 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
