The Foton 204 is a tractor with a rated output of 20 hp — making it one of the more compact options in its class. It is powered by a 2-cylinder diesel liquid-cooled engine, driving through four-wheel drive with a 6-speed gearbox. It is aimed at jobs of around up to 200 ac. Recorded specifications in UK and US units are listed below.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
20 hp
Catalogue coverage
Variants represented
2
Richest spec table
40 rows
Recorded power
20 hp
Transmissions
6-speed
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerFotonReference
Four-wheel driveReference
SteeringmanualReference
Drum brakesReference
Variants
2002WDReference
Engine
Foton 1.4L 2-cyl dieselReference
Engine14.7 kWReference
Foton TY290Reference
dieselReference
2-cylinderReference
liquid-cooledReference
Displacement1.4 LReference
Bore/Stroke90 x 100 mmReference
Power14.7 kWReference
Rated RPM2300Reference
Starter volts12Reference
Oil capacity3.5 LReference
Coolant capacity10.0 LReference
Transmission
6-speedReference
8-speedReference
Gears6 forward and 2 reverseReference
Gears8 forward and 2 reverseReference
Capacities
Fuel20.8 LReference
PTO & Hydraulics
Hydraulic system9.1 LReference
Capacity9.1 LReference
Pressure145.0 barReference
Rear Type0Reference
Rear PTOtransmissionReference
Rear PTO Type540/720Reference
Dimensions
Front tire6.00-12Reference
Rear tire8.3-24Reference
Ag front6.00-12Reference
Ag rear8.3-24Reference
Length270 cmReference
Width124 cmReference
Height136 cmReference
Ground clearance25 cmReference
Electrical
GroundnegativeReference
Charging amps16.7Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
