The Foton 220 is a tractor rated at 22 hp — making it one of the more compact options in its class. Under the hood is a 2-cylinder diesel liquid-cooled engine, driving through four-wheel drive with a 6-speed gearbox. It is aimed at jobs of around up to 200 ac. Recorded specifications in UK and US units are listed below.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
22 hp
Catalogue coverage
Variants represented
2
Richest spec table
40 rows
Recorded power
22 hp
Transmissions
6-speed
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerFotonReference
Two-wheel driveReference
SteeringmanualReference
Drum brakesReference
Variants
2244WDReference
Engine
Foton 1.5L 2-cyl dieselReference
Engine16.0 kWReference
Foton TY295IReference
dieselReference
2-cylinderReference
liquid-cooledReference
Displacement1.5 LReference
Bore/Stroke95 x 105 mmReference
Power16.0 kWReference
Rated RPM2200Reference
Starter volts12Reference
Oil capacity3.5 LReference
Coolant capacity10.0 LReference
Transmission
6-speedReference
8-speedReference
Gears6 forward and 2 reverseReference
Gears8 forward and 2 reverseReference
Capacities
Fuel20.8 LReference
PTO & Hydraulics
Hydraulic system9.1 LReference
Capacity9.1 LReference
Pressure145.0 barReference
Rear Type0Reference
Rear PTOtransmissionReference
Rear PTO Type540/720Reference
Dimensions
Front tire4.00-16Reference
Rear tire8.3-24Reference
Ag front4.00-16Reference
Ag rear8.3-24Reference
Length275 cmReference
Width124 cmReference
Height136 cmReference
Ground clearance32 cmReference
Electrical
GroundnegativeReference
Charging amps16.7Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
