The Foton 304 is a tractor rated at 28 hp, positioning it at the lighter end of its class. It is equipped with a 3-cylinder diesel liquid-cooled engine, paired with a four-wheel drive system and an 8-speed gearbox. The tractor has an operating weight of 1784 kg and is suitable for operations spanning up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
28 hp
Weight
1784 kg
Catalogue coverage
Variants represented
2
Richest spec table
39 rows
Recorded power
28 hp
Recorded weight
1784 kg
Transmissions
8-speed
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerFotonReference
Four-wheel driveReference
Wet disc brakesReference
Variants
3002WDReference
Engine
2.2L 3-cyl dieselReference
Engine22.1 kWReference
TY395TReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.2 LReference
Bore/Stroke95 x 105 mmReference
Power22.1 kWReference
Compression18:1Reference
Rated RPM2200Reference
Torque106.0 NmReference
Torque RPM1725Reference
Starter volts12Reference
Oil capacity7.0 LReference
Coolant capacity8.4 LReference
Transmission
8-speedReference
Gears8 forward and 4 reverseReference
PTO & Hydraulics
PTO (claimed)20.5 kWReference
Hydraulic system10.2 LReference
Capacity10.2 LReference
Rear PTOliveReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase187 cmReference
Weight1784 kgReference
Front tire6.50-16Reference
Rear tire11.2-24Reference
Ag front6.50-16Reference
Ag rear11.2-24Reference
Length351 cmReference
Width165 cmReference
Height207 cmReference
Ground clearance24 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
