Tractor · Unverified
Foton 350
Foton 350 · 32 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
32 hp
Weight
1677 kg
Hover a source tag to verify
Overview
ManufacturerFotonReference
Two-wheel driveReference
Wet disc brakesReference
Two-post foldable ROPS. Cab optional.Reference
Variants
3502WDReference
3544WDReference
Engine
2.2L 3-cyl dieselReference
Engine25.7 kWReference
TY395TReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.2 LReference
Bore/Stroke95 x 105 mmReference
Power25.7 kWReference
Compression18:1Reference
Rated RPM2400Reference
Torque118.0 NmReference
Torque RPM1725Reference
Starter volts12Reference
Oil capacity7.0 LReference
Coolant capacity8.4 LReference
Transmission
8-speedReference
Gears8 forward and 4 reverseReference
Gears8 forward and reverseReference
PTO & Hydraulics
PTO (claimed)23.9 kWReference
Hydraulic system10.2 LReference
Capacity10.2 LReference
Rear TypeIReference
Rear lift (at 24"/610mm)591 kgReference
Rear PTOliveReference
Rear PTO Type540/1000Reference
Capacities
Fuel29.1 LReference
Dimensions
Wheelbase187 cmReference
Weight1677 kgReference
Front tire5.50-16Reference
Rear tire11.2-28Reference
Ag front5.50-16Reference
Ag rear11.2-28Reference
Length351 cmReference
Width171 cmReference
Height210 cmReference
Ground clearance36 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
