The Foton 354 is a tractor model rated at 32 hp — making it one of the more compact options in its class. Power comes from a 3-cylinder diesel liquid-cooled engine, driving through four-wheel drive with a 8-speed gearbox. Listed weight is 1799 kg, and it is aimed at jobs of around up to 200 ac. Available dimensions and performance figures follow in both unit systems.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
32 hp
Weight
1799 kg
Catalogue coverage
Variants represented
2
Richest spec table
45 rows
Recorded power
32 hp
Recorded weight
1799 kg
Transmissions
8-speed
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerFotonReference
Four-wheel driveReference
Wet disc brakesReference
Two-post foldable ROPS. Cab optional.Reference
Variants
3502WDReference
3544WDReference
Engine
2.2L 3-cyl dieselReference
Engine25.7 kWReference
TY395TReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.2 LReference
Bore/Stroke95 x 105 mmReference
Power25.7 kWReference
Compression18:1Reference
Rated RPM2400Reference
Torque118.0 NmReference
Torque RPM1725Reference
Starter volts12Reference
Oil capacity7.0 LReference
Coolant capacity8.4 LReference
Transmission
8-speedReference
Gears8 forward and 4 reverseReference
Gears8 forward and reverseReference
PTO & Hydraulics
PTO (claimed)23.9 kWReference
Hydraulic system10.2 LReference
Capacity10.2 LReference
Rear TypeIReference
Rear lift (at 24"/610mm)591 kgReference
Rear PTOliveReference
Rear PTO Type540/1000Reference
Capacities
Fuel29.1 LReference
Dimensions
Wheelbase187 cmReference
Weight1799 kgReference
Front tire7.50-16Reference
Rear tire11.2-28Reference
Ag front7.50-16Reference
Ag rear11.2-28Reference
Length351 cmReference
Width165 cmReference
Height210 cmReference
Ground clearance29 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
