Foton 400
Foton 400 · 37 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
37 hp
Weight
1784 kg
Hover a source tag to verify
Overview
ManufacturerFotonReference
Two-wheel driveReference
Wet disc brakesReference
Variants
4044WDReference
Engine
2.9L 3-cyl dieselReference
Engine29.4 kWReference
SL3105BTReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.9 LReference
Bore/Stroke105 x 110 mmReference
Power29.4 kWReference
Compression17:1Reference
Rated RPM2200Reference
Torque146.4 NmReference
Torque RPM1650Reference
Starter volts12Reference
Oil capacity7.0 LReference
Coolant capacity8.4 LReference
Transmission
8-speedReference
Gears8 forward and 3 reverseReference
PTO & Hydraulics
PTO (claimed)27.2 kWReference
Hydraulic system10.2 LReference
Capacity10.2 LReference
Rear PTOliveReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase187 cmReference
Weight1784 kgReference
Front tire6.00-16Reference
Rear tire12.4-28Reference
Ag front6.00-16Reference
Ag rear12.4-28Reference
Length351 cmReference
Width183 cmReference
Height212 cmReference
Ground clearance39 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
