The Foton 404 is a compact tractor with a rated output of 37 hp. It features a 3-cylinder diesel liquid-cooled engine, coupled with a four-wheel drive system and an 8-speed gearbox. The tractor's listed weight is 1920 kg and is suited for jobs covering up to 200 ac. Detailed specifications are available for both the UK and US markets.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
37 hp
Weight
1920 kg
Catalogue coverage
Variants represented
2
Richest spec table
39 rows
Recorded power
37 hp
Recorded weight
1920 kg
Transmissions
8-speed
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerFotonReference
Four-wheel driveReference
Wet disc brakesReference
Variants
4002WDReference
Engine
2.9L 3-cyl dieselReference
Engine29.4 kWReference
SL3105BTReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.9 LReference
Bore/Stroke105 x 110 mmReference
Power29.4 kWReference
Compression17:1Reference
Rated RPM2200Reference
Torque146.4 NmReference
Torque RPM1650Reference
Starter volts12Reference
Oil capacity7.0 LReference
Coolant capacity8.4 LReference
Transmission
8-speedReference
Gears8 forward and 3 reverseReference
PTO & Hydraulics
PTO (claimed)27.2 kWReference
Hydraulic system10.2 LReference
Capacity10.2 LReference
Rear PTOliveReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase192 cmReference
Weight1920 kgReference
Front tire6.00-16Reference
Rear tire12.4-28Reference
Ag front6.00-16Reference
Ag rear12.4-28Reference
Length351 cmReference
Width175 cmReference
Height212 cmReference
Ground clearance40 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
