The Foton 500 tractor is a model with a rating of 46 hp, positioning it at the lighter end of its class. It is equipped with a 4-cylinder diesel liquid-cooled engine, combined with a four-wheel drive system and an 8-speed gearbox. The tractor's operating weight is listed at 2980 kg, with a capability of handling up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
46 hp
Weight
2980 kg
Catalogue coverage
Variants represented
2
Richest spec table
34 rows
Recorded power
46 hp
Recorded weight
2980 kg
Transmissions
8-speed
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerFotonReference
Two-wheel driveReference
Variants
5044WDReference
Engine
3.8L 4-cyl dieselReference
Fuel tank78.0 LReference
Engine36.8 kWReference
YZ4100TB1Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.8 LReference
Bore/Stroke100 x 122 mmReference
Power36.8 kWReference
Compression17:1Reference
Rated RPM2200Reference
Torque194.7 NmReference
Torque RPM1650Reference
Oil capacity10.0 LReference
Transmission
8-speedReference
Gears8 forward and 2 reverseReference
PTO & Hydraulics
PTO (claimed)34.6 kWReference
Rear TypeI,IIReference
Rear lift (at 24"/610mm)866 kgReference
Rear PTO Type540Reference
Dimensions
Wheelbase218 cmReference
Weight2980 kgReference
Front tire6.00-16Reference
Rear tire14.9-28Reference
Ag front6.00-16Reference
Ag rear14.9-28Reference
Length409 cmReference
Width183 cmReference
Height269 cmReference
Weight2980 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
