The Foton 700 is a tractor with a rated power of 65 hp, a mid-range figure for its class. Power comes from a 4-cylinder diesel liquid-cooled engine, paired with four-wheel drive with a 8-speed gearbox. It has a listed operating weight of 3165 kg, and it suits operations of up to 200 ac. Available dimensions and performance figures follow in both unit systems.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
65 hp
Weight
3165 kg
Catalogue coverage
Variants represented
2
Richest spec table
44 rows
Recorded power
65 hp
Recorded weight
3165 kg
Transmissions
8-speed
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerFotonReference
Two-wheel driveReference
SteeringpowerReference
Disc brakesReference
Variants
7044WDReference
Engine
4.3L 4-cyl dieselReference
Engine51.5 kWReference
LRC4105T70Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.3 LReference
Bore/Stroke105 x 125 mmReference
Power51.5 kWReference
Compression17:1Reference
Rated RPM2200Reference
Torque257.1 NmReference
Torque RPM1400Reference
Oil capacity10.0 LReference
Coolant capacity14.0 LReference
Transmission
8-speedReference
Gears8 forward and 2 reverseReference
Gears8 forward and 4 reverseReference
PTO & Hydraulics
PTO (claimed)48.4 kWReference
Hydraulic system17.0 LReference
TypeopenReference
Capacity17.0 LReference
Rear TypeI,IIReference
Rear lift (at 24"/610mm)1223 kgReference
Rear PTO Type540Reference
Capacities
Fuel78.0 LReference
Dimensions
Wheelbase218 cmReference
Weight3165 kgReference
Front tire6.50-20Reference
Rear tire16.9-28Reference
Ag front6.50-20Reference
Ag rear16.9-28Reference
Length409 cmReference
Width195 cmReference
Height273 cmReference
Weight3165 kgReference
Electrical
GroundnegativeReference
Charging amps35.7Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
