Tractor · Unverified
Foton 820
Foton 820 · 81 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
81 hp
Weight
3590 kg
Hover a source tag to verify
Overview
ManufacturerFotonReference
Two-wheel driveReference
SteeringpowerReference
Disc brakesReference
Variants
8244WDReference
Engine
4.3L 4-cyl dieselReference
Engine60.7 kWReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.3 LReference
Bore/Stroke105 x 125 mmReference
Power60.7 kWReference
Rated RPM2300Reference
Oil capacity17.0 LReference
Coolant capacity14.0 LReference
Transmission
8-speedReference
Gears8 forward and 4 reverseReference
Capacities
Fuel99.9 LReference
PTO & Hydraulics
Hydraulic system17.0 LReference
TypeopenReference
Capacity17.0 LReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase236 cmReference
Weight3590 kgReference
Front tire6.50-16Reference
Rear tire13.6-38Reference
Ag front6.50-16Reference
Ag rear13.6-38Reference
Length424 cmReference
Width195 cmReference
Height280 cmReference
Ground clearance47 cmReference
Electrical
GroundnegativeReference
Charging amps35.7Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
