Tractor · 1976Unverified
GBT GBT-2000
GBT GBT-2000 — Tool Carrier tractor · 27 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
27 hp
Weight
1156 kg
Hover a source tag to verify
Overview
ManufacturerGBTReference
Tool Carrier tractorReference
Built in Madison, Wisconsin, USAReference
Original price was $4,600 in 1976Reference
Two-wheel driveReference
Manual steeringReference
Hydraulic disc brakesReference
Open operator station.Reference
Engine
Continental 0.8L 4-cyl gasolineReference
Engine20.1 kWReference
Continental R800-46Reference
gasolineReference
4-cylinderReference
liquid-cooledReference
Displacement0.8 LReference
Bore/Stroke58 x 80 mmReference
Power20.1 kWReference
Compression8:1Reference
Rated RPM3300Reference
StarterelectricReference
Starter volts12Reference
Coolant capacity4.7 LReference
Oil capacity2.8 LReference
Oil change50 hReference
Transmission
6-speed gearReference
TypegearReference
Gears6 forward and 1 reverseReference
Oil capacity5.6 LReference
Oil typeSAE90Reference
Capacities
Fuel34.9 LReference
PTO & Hydraulics
Hydraulic system16.1 LReference
Typeopen centerReference
Capacity16.1 LReference
Pressure103.4 barReference
Pump flow13.2 lpmReference
Dimensions
Wheelbase195 cmReference
Weight1156 kgReference
Front tire5.00x15Reference
Rear tire9.5x24Reference
Ag front5.00x15Reference
Ag rear9.5x24Reference
Ag rear11.2x24Reference
Length325 cmReference
Height (steering wheel)162 cmReference
Clearance (front axle)50 cmReference
Clearance (rear axle)50 cmReference
Front tread99 to 154 cmReference
Rear tread96 to 170 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Speeds
With 9.5x24 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
