Tractor · 1918Unverified
General Ordnance National Tractor 9-16 E
General Ordnance National Tractor 9-16 E — Standard-tread tractor · 9 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
9 hp
Weight
1723 kg
Hover a source tag to verify
Overview
ManufacturerGeneral OrdnanceReference
Standard-tread tractorReference
Built in Cedar Rapids, Iowa, USAReference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Engine
Waukseha 3.5L 4-cyl gasolineReference
Fuel tank75.7 LReference
Aux. fuel37.9 LReference
Drawbar (claimed)6.7 kWReference
Belt (claimed)11.9 kWReference
Plows2Reference
WauksehaReference
gasolineReference
4-cylinderReference
liquid-cooledReference
Displacement3.5 LReference
Bore/Stroke89 x 140 mmReference
Transmission
6-speed friction discReference
Typefriction discReference
Gears6 forward and reverseReference
Dimensions
Weight1723 kgReference
Rear tire46x10Reference
Ag rear46x10 steelReference
Length304 cmReference
Width144 cmReference
Height152 cmReference
Capacities
Diameter25 cmReference
Width15 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
