Tractor · 1947Unverified
Gibson D
Gibson D · 6 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
6 hp
Weight
433 kg
Hover a source tag to verify
Overview
ManufacturerGibsonReference
Built in Longmont, Colorado, USAReference
Two-wheel driveReference
Steeringmanual, tillerReference
Open operator station.Reference
Variants
SDhood and fendersReference
Engine
Wisconsin 0.4L 1-cyl gasolineReference
Fuel tank9.5 LReference
Engine4.5 kWReference
Plows1Reference
Wisconsin AEHReference
gasolineReference
1-cylinderReference
air-cooledReference
Displacement0.4 LReference
Bore/Stroke76 x 83 mmReference
Power4.5 kWReference
Air cleaneroil bathReference
Rated RPM2000Reference
Transmission
3-speed unsynchronized gearReference
Typeunsynchronized gearReference
Gears3 forward and 1 reverseReference
Clutchidler pulleyReference
Dimensions
Wheelbase116 cmReference
Weight433 kgReference
Front tire4.00x12Reference
Rear tire7.00-24Reference
Ag front4.00x12Reference
Ag rear7.00-24Reference
Height114 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
