Lawn Tractor · 1966Unverified
Gilson 723 Commander 1000
Gilson 723 Commander 1000 — C Series · 10 hp. Reference specifications; pending source verification.
The Gilson 723 Commander 1000 is a lawn tractor model with a 10 hp rated output, making it a relatively compact option in its class. It was produced from 1966 to 1969 and features a 1-cylinder petrol air-cooled engine, driving through two-wheel drive with a 3-speed gearbox. The listed weight of the Gilson 723 Commander 1000 is 252 kg, and it is designed for use on areas of up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
10 hp
Weight
252 kg
Catalogue coverage
Variants represented
2
Richest spec table
41 rows
Recorded power
10 hp
Recorded weight
252 kg
Transmissions
3-speed gear
Production years
1966-1969
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerGilsonReference
Garden tractorReference
Built in Plymouth, Wisconsin, USAReference
Original price was $799 in 1968Reference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Engine
10HP Kohler 391cc 1-cyl gasolineReference
Kohler K241Reference
gasolineReference
1-cylinderReference
air-cooledReference
Displacement23.9 ciReference
Bore/Stroke83 x 73 mmReference
Power (gross)7.5 kWReference
StarterelectricReference
Starter volts12Reference
Transmission
3-speed gearReference
Typebelt-driven gearReference
Gears3 forward and 1 reverseReference
PTO & Hydraulics
Typesleeve hitchReference
Dimensions
Weight252 kgReference
Front tire4.80x4.00-8Reference
Rear tire8.50-12Reference
Lawn/turf front4.80x4.00-8Reference
Lawn/turf rear8.50-12Reference
Length160 cmReference
Width91 cmReference
Height (steering wheel)93 cmReference
Shipping weight252 kgReference
Gilson 723 attachments
38" mid-mount mower deckReference
snowblowerReference
bladeReference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
38" mid-mount mower deckReference
SnowblowerReference
BladeReference
38" Mower deck
Typemid-mount Gilson 743Reference
Type2-blade with manual liftReference
Cutting width96 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
