Lawn Tractor · 1970Unverified
Gilson 865 RM-8E
Gilson 865 RM-8E — Riding lawn mower · 8 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
8 hp
Weight
141 kg
Hover a source tag to verify
Overview
ManufacturerGilsonReference
Riding lawn mowerReference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Variants
809manual startReference
865electric startReference
Engine
8HP Briggs & Stratton 318cc 1-cyl gasolineReference
Briggs & Stratton 190705Reference
gasolineReference
1-cylinderReference
air-cooled vertical shaftReference
Displacement19.44 ciReference
Bore/Stroke76 x 70 mmReference
Power (gross)6.0 kWReference
StarterelectricReference
Starter volts12Reference
Transmission
3-speed gearReference
Typebelt-driven gearReference
Gears3 forward and 1 reverseReference
Dimensions
Weight141 kgReference
Front tire10x4.10-4Reference
Rear tire16x6.50-8Reference
Lawn/turf front10x4.10-4Reference
Lawn/turf rear16x6.50-8Reference
Length138 cmReference
Width104 cmReference
Height (steering wheel)96 cmReference
Shipping weight141 kgReference
Gilson 865 attachments
34" mid-mount mower deckReference
Electrical
GroundnegativeReference
Battery volts12Reference
34" Mower deck
Typemid-mount GilsonReference
Type3-bladeReference
Cutting width86 cmReference
Min cut height0 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
