Lawn Tractor · 1988Unverified
Gravely 1238-H
Gravely 1238-H — Lawn tractor · 12 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
12 hp
Weight
477 to 487 pounds
Hover a source tag to verify
Overview
ManufacturerGravely (a part of Ariens)Reference
Lawn tractorReference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Engine
12HP Briggs & Stratton 465cc 1-cyl gasolineReference
12.5HP Kawasaki 1-cyl gasolineReference
Fuel tank6.6 LReference
Briggs & Stratton 281707Reference
gasolineReference
1-cylinderReference
air-cooled vertical-shaftReference
Displacement28.4 ciReference
Bore/Stroke87 x 78 mmReference
Power (gross)8.9 kWReference
StarterelectricReference
Starter volts12Reference
Oil capacity1.4 LReference
KawasakiReference
air-cooledReference
Power9.3 kWReference
Transmission
hydrostaticReference
TransmissionEaton 750Reference
Typebelt-driven hydrostaticReference
Gearsinfinite forward and reverseReference
Oil capacity2.0 LReference
PTO & Hydraulics
Mid PTOindependentReference
ClutchmanualReference
Mid PTO TypepulleyReference
Dimensions
Wheelbase116 cmReference
Weight477 to 487 poundsReference
Front tire13x5.00-6Reference
Rear tire18x8.50-8Reference
Lawn/turf front13x5.00-6Reference
Lawn/turf rear18x8.50-8Reference
Length157 cmReference
Height93 cmReference
Weight216 kgReference
Weight220 kgReference
Gravely 1238-H attachments
38" mid-mount mower deckReference
snowblowerReference
bladeReference
Electrical
GroundnegativeReference
Charging amps3 (Briggs)Reference
Charging amps13 (Kawasaki)Reference
Battery volts12Reference
Attachment overview
38" mid-mount mower deckReference
SnowblowerReference
BladeReference
38" Mower deck
Typemid-mount GravelyReference
Typemanual liftReference
Cutting width96 cmReference
Overall width125 cmReference
Cut height3 to 8 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
