Lawn Tractor · 1992Unverified
Gravely 14-G
Gravely 14-G — Model year 1992-19981999-2000 · 14 hp. Reference specifications; pending source verification.
The Gravely 14-G is a lawn tractor with a rated output of 14 horsepower, positioned in the middle of its class in terms of power. It was manufactured from 1992 to 2000. The 1-cylinder petrol air-cooled engine drives through two-wheel drive with an 8-speed gearbox. The listed weight of the Gravely 14-G is 386 kg, with an intended use for areas of approximately 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
14 hp
Weight
386 kg
Catalogue coverage
Variants represented
2
Richest spec table
46 rows
Recorded power
14 hp
Recorded weight
386 kg
Transmissions
8-speed gear
Production years
1992-2000
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerGravelyReference
Garden tractorReference
Two-wheel driveReference
Manual steeringReference
Mechanical band brakesReference
Open operator station.Reference
Engine
14HP Kohler 398cc 1-cyl gasolineReference
Fuel tank20.1 LReference
Kohler CH14SReference
gasolineReference
1-cylinderReference
air-cooled horizontal shaftReference
Displacement24.3 ciReference
Bore/Stroke87 x 67 mmReference
Power (gross)10.4 kWReference
Rated RPM3300Reference
StarterelectricReference
Starter volts12Reference
Oil capacity1.9 LReference
Transmission
8-speed gearReference
Typeshaft-driven gearReference
Gears8 forward and 4 reverseReference
Oil capacity5.7 LReference
Oil typeSC10W-30Reference
Dimensions
Wheelbase132 cmReference
Weight386 kgReference
Front tire16x6.50-8Reference
Rear tire23x8.50-12Reference
Lawn/turf front16x6.50-8Reference
Lawn/turf rear23x8.50-12Reference
Length208 cmReference
Width105 cmReference
Height129 cmReference
Gravely 14-G attachments
40" mid-mount mower deckReference
50" mid-mount mower deckReference
snowblowerReference
bladeReference
Electrical
GroundnegativeReference
Charging amps15Reference
Battery volts12Reference
Battery AH42Reference
Battery Group22FReference
Attachment overview
40" mid-mount mower deckReference
50" mid-mount mower deckReference
SnowblowerReference
BladeReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
