Lawn Tractor · 1988Unverified
Gravely 16-G
Gravely 16-G — Model year 1988-19981999-2001 · 16 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
16 hp
Weight
389 kg
Hover a source tag to verify
Overview
ManufacturerGravelyReference
Garden tractorReference
Two-wheel driveReference
Manual steeringReference
Mechanical band brakesReference
Open operator station.Reference
Engine
16HP Kohler 691cc 2-cyl gasolineReference
Fuel tank20.1 LReference
Kohler M18SReference
gasolineReference
2-cylinderReference
air-cooledReference
Displacement42.18 ciReference
Bore/Stroke79 x 70 mmReference
Power (gross)11.9 kWReference
Rated RPM3300Reference
StarterelectricReference
Starter volts12Reference
Oil capacity1.4 LReference
Transmission
8-speed gearReference
Typeshaft-driven gearReference
Gears8 forward and 4 reverseReference
Oil capacity5.7 LReference
Oil typeSC10W-30Reference
Dimensions
Wheelbase132 cmReference
Weight389 kgReference
Front tire16x6.50-8Reference
Rear tire23x8.50-12Reference
Lawn/turf front16x6.50-8Reference
Lawn/turf rear23x8.50-12Reference
Length208 cmReference
Width105 cmReference
Height129 cmReference
Gravely 16-G attachments
40" mid-mount mower deckReference
50" mid-mount mower deckReference
60" mid-mount mower deckReference
snowblowerReference
bladeReference
Electrical
GroundnegativeReference
Charging amps15Reference
Battery CCA42Reference
Battery volts12Reference
Battery Group22FReference
Attachment overview
40" mid-mount mower deckReference
50" mid-mount mower deckReference
60" mid-mount mower deckReference
SnowblowerReference
BladeReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
