Lawn Tractor · 1989Unverified
Gravely 24-G
Gravely 24-G — Professional G Series · 24 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
24 hp
Weight
436 kg
Hover a source tag to verify
Overview
ManufacturerGravelyReference
Garden tractorReference
Two-wheel driveReference
Power steeringReference
Open operator station.Reference
Engine
24HP Onan 978cc 2-cyl gasolineReference
Fuel tank20.1 LReference
Onan P224Reference
gasolineReference
2-cylinderReference
air-cooled horizontal-shaft horizontally-opposedReference
Displacement59.7 ciReference
Bore/Stroke90 x 76 mmReference
Power (gross)17.9 kWReference
Rated RPM3300Reference
StarterelectricReference
Starter volts12Reference
Oil capacity2.8 LReference
Transmission
8-speed gearReference
Typeshaft-driven gearReference
Gears8 forward and 4 reverseReference
Oil capacity5.2 LReference
Dimensions
Wheelbase152 cmReference
Weight436 kgReference
Front tire18x8.50-8Reference
Rear tire26x12.00-12Reference
Weight224 kgReference
Lawn/turf front18x8.50-8Reference
Lawn/turf rear26x12.00-12Reference
Length229 cmReference
Width117 cmReference
Height130 cmReference
Gravely 24-G attachments
72" mid-mount mower deckReference
bladeReference
Electrical
GroundnegativeReference
Charging amps20Reference
Battery volts12Reference
Attachment overview
72" mid-mount mower deckReference
BladeReference
72" Mower deck
Typemid-mount GravelyReference
Type3-bladeReference
Cutting width182 cmReference
Overall width213 cmReference
Cut height3 to 12 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
