Lawn Tractor · 1986Unverified
Gravely 8179-G
Gravely 8179-G — Garden tractor · 17 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
17 hp
Weight
854 to 895 pounds
Hover a source tag to verify
Overview
ManufacturerGravely (a part of Ariens)Reference
Garden tractorReference
Two-wheel driveReference
Manual steeringReference
Mechanical band brakesReference
Open operator station.Reference
Engine
17HP Kohler 691cc 2-cyl gasolineReference
Kohler KT-17Reference
gasolineReference
2-cylinderReference
air-cooled horizontal-shaftReference
Displacement42.18 ciReference
Bore/Stroke79 x 70 mmReference
Power (gross)12.7 kWReference
Rated RPM3600Reference
StarterelectricReference
Starter volts12Reference
Transmission
8-speed gearReference
Typeshaft-driven gearReference
Gears8 forward and 4 reverseReference
Oil capacity5.7 LReference
Oil type10W-40 SCReference
Four gears (1-4) in two ranges (low-high) with forward/reverse clutches. The directional clutch must be in neutral to shift gears or ranges.Reference
Capacities
Fuel20.1 LReference
PTO & Hydraulics
Hydraulic system0.9 LReference
Capacity0.9 LReference
Oil typeATF Dextron IIReference
Mid PTOindependentReference
Dimensions
Wheelbase132 cmReference
Weight854 to 895 poundsReference
Front tire16x7.50-8Reference
Rear tire23x10.50-12Reference
Lawn/turf front16x7.50-8Reference
Lawn/turf rear23x10.50-12Reference
Length208 cmReference
Width109 cmReference
Height116 cmReference
Weight387 kgReference
Shipping weight405 kgReference
5-bolt flange rear axleReference
Gravely 8179-G attachments
40" mid-mount mower deckReference
50" mid-mount mower deckReference
60" mid-mount mower deckReference
snowblowerReference
bladeReference
8179-G Serial Numbers
Location:Under hood on right side, on instrument panel support frame.Reference
Electrical
GroundnegativeReference
Battery volts12Reference
Battery AH42Reference
Battery GroupBCI 22FReference
Attachment overview
40" mid-mount mower deckReference
50" mid-mount mower deckReference
60" mid-mount mower deckReference
SnowblowerReference
BladeReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
