Tractor · 1914Unverified

Gray Tractor 20-35 A

Name: Gray Tractor 20-35 A
Brand: Gray Tractor

Gray Tractor 20-35 A — Standard-tread tractor · 20 hp. Reference specifications; pending source verification.

The Gray Tractor 20-35 A is a tractor model with a rated output of 20 hp — making it one of the more compact options in its class. This model was produced from 1914 to 1916. It is powered by a 4-cylinder petrol liquid-cooled engine, driving through a 2-speed gearbox. Listed weight is 3628 kg, and it is aimed at jobs of around up to 200 ac. The available specification table below shows both UK and US units.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

20 hp

Weight

3628 kg

Catalogue coverage

Variants represented

Richest spec table

30 rows

Recorded power

20 hp

Recorded weight

3628 kg

Transmissions

2-speed gear

Production years

1914-1916

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerGray TractorReference

Standard-tread tractorReference

Built in Minneapolis, Minnesota, USAReference

Original price was $2,150 in 1916Reference

Drive3x1 drum driveReference

Manual steeringReference

Open operator station.Reference

Engine

Waukesha 7.8L 4-cyl gasolineReference

Drawbar (claimed)14.9 kWReference

Belt (claimed)26.1 kWReference

Plows6Reference

WaukeshaReference

gasolineReference

4-cylinderReference

liquid-cooled inlineReference

Displacement7.8 LReference

Bore/Stroke121 x 171 mmReference

Transmission

2-speed gearReference

TypegearReference

Gears2 forward and 1 reverseReference

Dimensions

Weight3628 kgReference

Front tire44x10Reference

Rear tire60x60Reference

Ag front44x10 steelReference

Ag rear60x60 steelReference

Length515 cmReference

Width243 cmReference

Height182 cmReference

Capacities

Diameter30 cmReference

Width22 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
