Tractor · 1923Unverified

Gray Tractor 22-40 Canadian Special

Name: Gray Tractor 22-40 Canadian Special
Brand: Gray Tractor

Gray Tractor 22-40 Canadian Special — Standard-tread tractor · 22 hp. Reference specifications; pending source verification.

The Gray Tractor 22-40 Canadian Special is a tractor with a rated power output of 22 hp, categorising it at the lighter end of its class. This model was manufactured between 1923 and 1927. It features a 4-cylinder petrol liquid-cooled engine, paired with a 2-speed gearbox, and has an operating weight of 3129 kg. Its applications are suited to areas of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

22 hp

Weight

3129 kg

Catalogue coverage

Variants represented

Richest spec table

33 rows

Recorded power

22 hp

Recorded weight

3129 kg

Transmissions

2-speed gear

Production years

1923-1927

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerGray TractorReference

Standard-tread tractorReference

Built in Minneapolis, Minnesota, USAReference

Original price was $2,385 in 1925Reference

Drive3x1 drum driveReference

Manual steeringReference

Open operator station.Reference

Engine

Waukesha 8.0L 4-cyl gasolineReference

Drawbar (claimed)16.4 kWReference

Belt (claimed)29.8 kWReference

Plows4Reference

Waukesha EUReference

gasolineReference

4-cylinderReference

liquid-cooled inlineReference

Displacement8.0 LReference

Bore/Stroke127 x 159 mmReference

Rated RPM1000Reference

Image courtesy of Ronald TulaczReference

Transmission

2-speed gearReference

TypegearReference

Gears2 forward and 1 reverseReference

Dimensions

Weight3129 kgReference

Front tire40x8Reference

Rear tire54x54Reference

Ag front40x8 steelReference

Ag rear54x54 steelReference

Length439 cmReference

Width203 cmReference

Height163 cmReference

Capacities

Diameter28 cmReference

Width20 cmReference

Speed868.68 meters/minReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
