Tractor · 1916Unverified
Hart-Parr Steel King
Hart-Parr Steel King · 27 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
27 hp
Weight
7198 kg
Hover a source tag to verify
Overview
ManufacturerHart-ParrReference
Built in Charles City, IowaReference
Two-wheel driveReference
Engine
Hart-Parr 19.8L 2-cyl keroseneReference
Fuel tank189.2 LReference
Drawbar (claimed)20.1 kWReference
Belt (claimed)29.8 kWReference
Hart-ParrReference
keroseneReference
2-cylinderReference
liquid-cooledReference
Displacement19.8 LReference
Bore/Stroke203 x 305 mmReference
Rated RPM400Reference
Coolant capacity189.3 LReference
Transmission
2-speedReference
TransmissiongearReference
Gears2 forward and 1 reverseReference
Dimensions
Weight7198 kgReference
Length485 cmReference
Width241 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
