Tractor · 1974Unverified
Hefty LNT
Hefty LNT — Orchard/Vineyard tractor · 24 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
24 hp
Weight
975 kg
Hover a source tag to verify
Overview
ManufacturerHeftyReference
Orchard/Vineyard tractorReference
Built in Juneau, Wisconsin, USAReference
Two-wheel driveReference
Manual steeringReference
Mechanical disc brakesReference
Open operator station.Reference
Engine
Continental 0.8L 4-cyl gasolineReference
Fuel tank18.9 LReference
Engine20.1 kWReference
Continental R800-46Reference
gasolineReference
4-cylinderReference
liquid-cooledReference
The Continental R800 engine was built by Renault.Reference
Displacement0.8 LReference
Bore/Stroke58 x 80 mmReference
Power20.1 kWReference
Compression8:1Reference
Rated RPM3300Reference
Firing order1-3-4-2Reference
StarterelectricReference
Starter volts12Reference
Transmission
6-speed gearReference
TypegearReference
Gears6 forward and 1 reverseReference
PTO & Hydraulics
PTO (claimed)17.9 kWReference
Typeopen centerReference
Pressure137.9 barReference
Pump flow12.1 lpmReference
Rear TypeIReference
Controlposition controlReference
Rear lift (at ends)712 kgReference
Rear lift (at 24"/610mm)548 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Dimensions
Wheelbase182 cmReference
Weight975 kgReference
Front tire4.00x15Reference
Rear tire8.3x24Reference
Ag front4.00x15Reference
Ag rear8.3x24Reference
Height144 cmReference
Shipping weight975 kgReference
Front tread81 to 101 cmReference
Rear tread68 to 119 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
