Tractor · 1981Unverified
Hesston 1180
Hesston 1180 — 80 Series · 107 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
107 hp
Max power
69.9 kW
Weight
11800 to 13100 pounds
Hover a source tag to verify
Overview
ManufacturerHesston (a part of Fiat)Reference
Row-Crop tractorReference
Original price$33,500 (1984)Reference
Drive4x2 2WDReference
Drive4x4 MFWD 4WD optionalReference
Steeringhydrostatic powerReference
Hydraulic disc brakesReference
Supercomfort cab standard with air conditioningReference
Variants
1180DT4WDReference
Engine
Fiat 5.5L 6-cyl dieselReference
Fuel tank280.1 LReference
Drawbar (tested)69.9 kWReference
Fiat 8065Reference
turbocharged dieselReference
6-cylinderReference
liquid-cooledReference
Displacement5.5 LReference
Bore/Stroke103 x 110 mmReference
Compression15.7:1Reference
Rated RPM2550Reference
Starter volts12Reference
Power at rated engine speed80.1 kWReference
Max power69.9 kWReference
Transmission
12-speedReference
24-speedReference
Gears12 forward and 4 reverseReference
Gears24 forward and 8 reverseReference
Gears12 forward and reverseReference
PTO & Hydraulics
PTO (claimed)76.1 kWReference
PTO (tested)80.1 kWReference
Typeopen centerReference
Pressure168.9 barReference
Valves2Reference
Pump flow50.3 lpmReference
Rear TypeIIReference
Rear TypeIIIN optionalReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Power at rated PTO speed77.7 kWReference
Dimensions
Wheelbase275 cmReference
Wheelbase267 cmReference
Weight11800 to 13100 poundsReference
Front tire11.00-16Reference
Rear tire18.4-38Reference
Ag front11.00-16 (2WD)Reference
Ag front14.9-28 (4WD)Reference
Ag rear18.4-38Reference
Length413 cmReference
Length418 cmReference
Height (hood)179 cmReference
Height (cab)284 cmReference
Operating weight5352 kgReference
Operating weight5942 kgReference
Electrical
Charging systemalternatorReference
Charging amps65Reference
Test results
Diesel 12-speed 4WDSeptember 14 - 27, 1982Link: Nebraska Tractor Test 1450 fileReference
PTO performanceReference
Fuel use25.4 l/hourReference
Fuel use24.2 l/hourReference
Drawbar performanceReference
Fuel use25.0 l/hourReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
