Tractor · 1985Unverified

Hesston 130-90

Name: Hesston 130-90
Brand: Hesston

Hesston 130-90 — Row-Crop tractor · 107 hp. Reference specifications; pending source verification.

The Hesston 130-90 is a tractor with a rated power of 107 hp, a power output typical for its class. It was manufactured from 1985 to 1990. The tractor is equipped with a 6-cylinder turbocharged diesel liquid-cooled engine, coupled with mechanical front-wheel drive and a powershift transmission. Its operating weight is specified as between 11800 and 14240 pounds, with a suitability for operations covering 200–800 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

107 hp

Max power

67.5 kW

Weight

11800 to 14240 pounds

Catalogue coverage

Variants represented

Richest spec table

71 rows

Recorded power

107 hp

Transmissions

16-speed synchronized

Production years

1985-1990

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

DistributorHesstonReference

ManufacturerFiatReference

Row-Crop tractorReference

Original price was $51,000 in 1990Reference

Drive4x2 2WDReference

Drive4x4 MFWD 4WD (130-90DT)Reference

Power steeringReference

Hydraulic disc brakesReference

Supercomfort cab standard with air conditioningReference

Variants

130-902WDReference

130-90DT4WDReference

Engine

Fiat 5.9L 6-cyl dieselReference

Fuel tank280.1 LReference

Drawbar (tested)67.5 kWReference

Fiat 8065.25Reference

turbocharged dieselReference

6-cylinderReference

liquid-cooledReference

Displacement5.9 LReference

Bore/Stroke104 x 115 mmReference

Compression16.5:1Reference

Rated RPM2500Reference

Starter volts12Reference

Power at rated engine speed80.1 kWReference

Max power67.5 kWReference

Transmission

16-speed synchronizedReference

24-speed creeperReference

16-speed partial power shiftReference

TypesynchronizedReference

Gears16 forward and reverseReference

TypecreeperReference

Gears24 forward and 8 reverseReference

Typepartial power shiftReference

Four power-shift gears in four ranges.Reference

PTO & Hydraulics

PTO (claimed)79.8 kWReference

PTO (tested)80.1 kWReference

Pressure168.9 barReference

Valves3Reference

Pump flow50.7 lpmReference

Rear TypeIIReference

Rear TypeII/IIIReference

Rear lift3194 kgReference

Rear PTOindependentReference

Rear PTO Type540/1000Reference

Power at rated PTO speed79.6 kWReference

Dimensions

2WD Wheelbase274 cmReference

4WD Wheelbase267 cmReference

Weight11800 to 14240 poundsReference

Front tire11.00-16Reference

Rear tire18.4-38Reference

2WD Ag front11.00-16Reference

4WD Ag front14.9-28Reference

Ag rear18.4-38Reference

2WD Length413 cmReference

4WD Length418 cmReference

2WD Shipping5352 kgReference

4WD Shipping5942 kgReference

4WD Operating6459 kgReference

Ballasted7432 kgReference

Electrical

Charging systemalternatorReference

Charging amps65Reference

Battery volts12Reference

Hesston 130-90 Height

2WD Hood179 cmReference

4WD Hood179 cmReference

Cab284 cmReference

Test results

Diesel 16-speed 4WDApril 18 - May 4, 1985Link: Nebraska Tractor Test 1564 fileReference

PTO performanceReference

Fuel use25.0 l/hourReference

Fuel use24.6 l/hourReference

Drawbar performanceReference

Max pull6735 kgReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
