Tractor · 1981Unverified
Hesston 1580
Hesston 1580 — 80 Series · 141 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
141 hp
Max power
91.8 kW
Weight
13350 to 15200 pounds
Hover a source tag to verify
Overview
ManufacturerHesston (a part of Fiat)Reference
Row-Crop tractorReference
Original price was $50,000 in 1984Reference
Two- or four-wheel driveReference
Steeringhydrostatic powerReference
Hydraulic disc brakesReference
Supercomfort cab standard with air conditioningReference
Variants
1580DT4WDReference
Engine
Fiat 8.1L 6-cyl dieselReference
Fuel tank280.1 LReference
Drawbar (claimed)92.5 kWReference
Drawbar (tested)91.8 kWReference
Fiat 8365-05Reference
turbocharged dieselReference
6-cylinderReference
liquid-cooledReference
Displacement8.1 LReference
Bore/Stroke115 x 130 mmReference
Compression15.5:1Reference
Rated RPM2200Reference
Starter volts12Reference
Power at rated engine speed105.5 kWReference
Max power91.8 kWReference
Transmission
12-speedReference
24-speedReference
Gears12 forward and 4 reverseReference
Clutchhydraulic dry discReference
Four gears (1-4) in three ranges (L, M, H).Reference
Gears24 forward and 8 reverseReference
Gears12 forward and reverseReference
PTO & Hydraulics
PTO (claimed)102.9 kWReference
PTO (tested)105.5 kWReference
Typeopen centerReference
Pressure168.9 barReference
Valves3Reference
Pump flow55.6 lpmReference
Rear TypeIIReference
Rear TypeIIIN optionalReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Power at rated PTO speed101.5 kWReference
Dimensions
Wheelbase296 cmReference
Wheelbase288 cmReference
Weight13350 to 15200 poundsReference
Front tire11.00-16Reference
Rear tire18.4-38Reference
Ag front11.00-16 (2WD)Reference
Ag front14.9-28 (4WD)Reference
Ag rear18.4-38Reference
2WD Length432 cmReference
4WD Length443 cmReference
2WD Operating weight6055 kgReference
4WD Operating weight6894 kgReference
Electrical
Charging systemalternatorReference
Charging amps65Reference
Hesston 1580 Height
2WD Hood183 cmReference
4WD Hood182 cmReference
Cab285 cmReference
Test results
Diesel 12-speed 4WDSeptember 13 - 23, 1982Link: Nebraska Tractor Test 1451 fileReference
PTO performanceReference
Fuel use31.8 l/hourReference
Fuel use29.9 l/hourReference
Drawbar performanceReference
Fuel use31.4 l/hourReference
Max pull6959 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
