Tractor · 1985Unverified

Hesston 180-90

Name: Hesston 180-90
Brand: Hesston

Hesston 180-90 — Row-Crop tractor · 163 hp. Reference specifications; pending source verification.

The Hesston 180-90 is a tractor with a power rating of approximately 163 hp, placing it towards the higher end of its class. It was manufactured between 1985 and 1991. The model features a 6-cylinder turbocharged diesel liquid-cooled engine, coupled with four-wheel drive and a hydrostatic transmission, and has an operating weight of between 13448 and 15520 pounds. It is suitable for operations covering 600–1,500 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

163 hp

Max power

102.8 kW

Weight

13448 to 15520 pounds

Catalogue coverage

Variants represented

Richest spec table

83 rows

Recorded power

163 hp

Transmissions

16-speed synchronized

Production years

1985-1991

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

DistributorHesstonReference

ManufacturerFiatReference

Row-Crop tractorReference

Original price$64,000 (1990)Reference

Two- or four-wheel driveReference

Steeringhydrostatic powerReference

Hydraulic disc brakesReference

Variants

180-902WDReference

180-90DT4WDReference

180-90similar Fiat modelReference

Engine

Fiat-Iveco 8.1L 6-cyl dieselReference

Fuel tank280.1 LReference

Drawbar (tested)103.3 kWReference

Fiat-Iveco 8365.25Reference

turbocharged dieselReference

6-cylinderReference

liquid-cooledReference

Displacement8.1 LReference

Bore/Stroke115 x 130 mmReference

Fuel systemdirect injectionReference

Compression15.5:1Reference

Rated RPM2200Reference

Starter volts12Reference

Power at rated engine speed121.5 kWReference

Max power102.8 kWReference

Power at rated engine speed120.9 kWReference

Max power103.3 kWReference

Transmission

16-speed synchronizedReference

24-speed creeperReference

16-speed partial power shiftReference

TypesynchronizedReference

Gears16 forward and reverseReference

Four gears (1-4) in four ranges (I-IV).Reference

TypecreeperReference

Gears24 forward and 8 reverseReference

Four gears (1-4) in three ranges (low/normal/high) with normal and creeper mode.Reference

Typepartial power shiftReference

Four power-shift gears (1-4) in four ranges (I-IV).Reference

PTO & Hydraulics

PTO (claimed)120.8 kWReference

PTO (tested)121.5 kWReference

Pressure168.9 barReference

Valves3Reference

Pump flow55.6 lpmReference

Rear TypeII/IIIReference

Rear lift5783 kgReference

Rear PTOindependentReference

Rear PTO Type1000Reference

Power at rated PTO speed118.3 kWReference

Power at rated PTO speed120.1 kWReference

Dimensions

4WD Wheelbase296 cmReference

4WD Wheelbase288 cmReference

Weight13448 to 15520 poundsReference

Front tire11.00-16Reference

Rear tire20.8-38Reference

4WD Ag front11.00-16Reference

4WD Ag front16.9-28Reference

Ag rear20.8-38Reference

4WD Length436 cmReference

4WD Length450 cmReference

4WD Shipping6100 kgReference

4WD Shipping6494 kgReference

4WD Operating7039 kgReference

Ballasted8947 kgReference

Electrical

Charging systemalternatorReference

Charging amps65Reference

Hesston 180-90 Height

4WD Hood183 cmReference

4WD Hood182 cmReference

Cab293 cmReference

Test results

NTTL 1535: diesel 16-speed synchro 4WDReference

NTTL 1581: diesel 16-speed powershift 4WDReference

Diesel 16-speed synchro 4WDSeptember 25 - October 4, 1984Link: Nebraska Tractor Test 1535 fileReference

PTO performanceReference

Fuel use35.6 l/hourReference

Fuel use33.7 l/hourReference

Drawbar performanceReference

Fuel use34.8 l/hourReference

Max pull6673 kgReference

Diesel 16-speed powershift 4WDOctober 2 - 16, 1985Link: Nebraska Tractor Test 1581 fileReference

Fuel use38.2 l/hourReference

Fuel use36.3 l/hourReference

Fuel use37.5 l/hourReference

Max pull8951 kgReference

Speeds

With 20.8-38 rear tires.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
