Tractor · 1983Unverified
Hesston 466
Hesston 466 — Utility tractor · 45 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
45 hp
Max power
28.7 kW
Weight
4851 to 5720 pounds
Hover a source tag to verify
Overview
DistributorHesstonReference
ManufacturerFiatReference
Utility tractorReference
Built in Modena, ItalyReference
Original price was $16,400 in 1984Reference
Two- or four-wheel driveReference
Power steeringReference
Differential mechanical wet disc brakesReference
Four-post ROPS standard. Optional canopy.Reference
Variants
466DT4WDReference
Engine
Fiat 2.6L 3-cyl dieselReference
Fuel tank72.7 LReference
Drawbar (claimed)29.8 kWReference
Drawbar (tested)28.7 kWReference
Fiat 8035.02Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.6 LReference
Bore/Stroke100 x 110 mmReference
Compression17:1Reference
Rated RPM2600Reference
Starter volts12Reference
Power at rated engine speed33.7 kWReference
Max power28.7 kWReference
Transmission
12-speed synchronizedReference
12-speedReference
20-speedReference
TypesynchronizedReference
Gears12 forward and 4 reverseReference
Four synchronized gears in three ranges.Reference
Gears12 forward and reverseReference
Gears20 forward and 8 reverseReference
PTO & Hydraulics
PTO (claimed)33.6 kWReference
PTO (tested)33.7 kWReference
Typeopen centerReference
Pressure186.2 barReference
Valves0 to 2Reference
Pump flow41.6 lpmReference
Rear TypeI/IIReference
Rear PTOindependentReference
Rear PTO Type540Reference
Power at rated PTO speed31.8 kWReference
Dimensions
2WD Wheelbase217 cmReference
4WD Wheelbase211 cmReference
Weight4851 to 5720 poundsReference
Front tire6.00-16Reference
Rear tire13.6-28Reference
2WD Ag front6.00-16Reference
4WD Ag front9.5-24Reference
2WD Ag rear13.6-28Reference
4WD Ag rear16.9-28Reference
2WD Length330 cmReference
4WD Length337 cmReference
2WD Clearance (front axle)50 cmReference
4WD Clearance (front axle)43 cmReference
2WD Operating2200 kgReference
4WD Operating2594 kgReference
Ballasted3025 kgReference
Electrical
Charging systemalternatorReference
Charging amps33Reference
Hesston 466 Height
2WD Hood144 cmReference
4WD Hood147 cmReference
Exhaust238 cmReference
Test results
Diesel 12-speed 4WDJune 9 - 22, 1983Link: Nebraska Tractor Test 1484 fileReference
PTO performanceReference
Fuel use11.0 l/hourReference
Fuel use9.5 l/hourReference
Drawbar performanceReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
