Tractor · 1983Unverified

Hesston 466

Name: Hesston 466
Brand: Hesston

Hesston 466 — Utility tractor · 45 hp. Reference specifications; pending source verification.

The Hesston 466 is a tractor with a rated output of 45 hp, positioning it among the more compact options in its class. It was manufactured from 1983 to 1984. The tractor features a 3-cylinder diesel liquid-cooled engine, paired with a 12-speed gearbox and four-wheel drive capability. Its listed weight ranges from 4851 to 5720 pounds, suitable for tasks covering approximately 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

45 hp

Max power

28.7 kW

Weight

4851 to 5720 pounds

Catalogue coverage

Variants represented

Richest spec table

69 rows

Recorded power

45 hp

Transmissions

12-speed synchronized

Production years

1983-1984

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

DistributorHesstonReference

ManufacturerFiatReference

Utility tractorReference

Built in Modena, ItalyReference

Original price was $16,400 in 1984Reference

Two- or four-wheel driveReference

Power steeringReference

Differential mechanical wet disc brakesReference

Four-post ROPS standard. Optional canopy.Reference

Variants

466DT4WDReference

Engine

Fiat 2.6L 3-cyl dieselReference

Fuel tank72.7 LReference

Drawbar (claimed)29.8 kWReference

Drawbar (tested)28.7 kWReference

Fiat 8035.02Reference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement2.6 LReference

Bore/Stroke100 x 110 mmReference

Compression17:1Reference

Rated RPM2600Reference

Starter volts12Reference

Power at rated engine speed33.7 kWReference

Max power28.7 kWReference

Transmission

12-speed synchronizedReference

12-speedReference

20-speedReference

TypesynchronizedReference

Gears12 forward and 4 reverseReference

Four synchronized gears in three ranges.Reference

Gears12 forward and reverseReference

Gears20 forward and 8 reverseReference

PTO & Hydraulics

PTO (claimed)33.6 kWReference

PTO (tested)33.7 kWReference

Typeopen centerReference

Pressure186.2 barReference

Valves0 to 2Reference

Pump flow41.6 lpmReference

Rear TypeI/IIReference

Rear PTOindependentReference

Rear PTO Type540Reference

Power at rated PTO speed31.8 kWReference

Dimensions

2WD Wheelbase217 cmReference

4WD Wheelbase211 cmReference

Weight4851 to 5720 poundsReference

Front tire6.00-16Reference

Rear tire13.6-28Reference

2WD Ag front6.00-16Reference

4WD Ag front9.5-24Reference

2WD Ag rear13.6-28Reference

4WD Ag rear16.9-28Reference

2WD Length330 cmReference

4WD Length337 cmReference

2WD Clearance (front axle)50 cmReference

4WD Clearance (front axle)43 cmReference

2WD Operating2200 kgReference

4WD Operating2594 kgReference

Ballasted3025 kgReference

Electrical

Charging systemalternatorReference

Charging amps33Reference

Hesston 466 Height

2WD Hood144 cmReference

4WD Hood147 cmReference

Exhaust238 cmReference

Test results

Diesel 12-speed 4WDJune 9 - 22, 1983Link: Nebraska Tractor Test 1484 fileReference

PTO performanceReference

Fuel use11.0 l/hourReference

Fuel use9.5 l/hourReference

Drawbar performanceReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
