Tractor · 1990Unverified
Hesston 60-56
Hesston 60-56 — 56 Series · 60 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
60 hp
Weight
2315 kg
Hover a source tag to verify
Overview
DistributorHesstonReference
ManufacturerFiatReference
Utility tractorReference
Two- or four-wheel driveReference
ROPS with canopy.Reference
Variants
60-56DT4WDReference
Engine
Fiat 2.9L 3-cyl dieselReference
Engine44.7 kWReference
Fiat 8035.05Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.9 LReference
Bore/Stroke104 x 115 mmReference
Power44.7 kWReference
Fuel systemdirect injectionReference
Compression17:1Reference
Rated RPM2500Reference
StarterelectricReference
Starter volts12Reference
Transmission
8-speed partially synchronizedReference
12-speed partially synchronizedReference
Typepartially synchronizedReference
Gears8 forward and 2 reverseReference
Four gears (1-4), plus reverse (R), in two ranges (I/II)Reference
Gears12 forward and 3 reverseReference
Four gears (1-4), plus reverse (R), in three ranges (I, II, and III).Reference
PTO & Hydraulics
Rear TypeII/IReference
Rear PTOindependentReference
Rear PTO Type540Reference
Dimensions
2WD Wheelbase205 cmReference
2WD Wheelbase201 cmReference
Weight2315 kgReference
Front tire7.50-16Reference
2WD Rear tire16.9-28Reference
2WD Standard tires (ag)Front: 7.50-16. Rear: 16.9-28Reference
2WD Standard tires (ag)Front: 9.5-24. Rear: 16.9-28Reference
2WD Length320 cmReference
4WD Length327 cmReference
Operating weight2315 kgReference
Ballasted weight3053 kgReference
4WD Ground clearance32 cmReference
2WD Ground clearance49 cmReference
2WD Front tread139 to 199 cmReference
4WD Front tread144 to 187 cmReference
Rear tread131 to 191 cmReference
Steering wheel146 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Hesston 60-56 Height
Hood143 cmReference
2WD ROPS229 cmReference
4WD ROPS228 cmReference
Exhaust236 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
