Tractor · 1984Unverified
Hesston 60-90
Hesston 60-90 — 90 Series · 51 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
51 hp
Weight
6292 to 6754 pounds
Hover a source tag to verify
Overview
DistributorHesstonReference
ManufacturerFiatReference
Utility tractorReference
Original price was $27,300 in 1988Reference
Two- or four-wheel driveReference
Final drivesplanetaryReference
Differential lockmechanical rearReference
Power steeringReference
Differential hydraulic wet disc brakesReference
Four-post ROPS. Cab optional.Reference
Variants
60-90DT4WDReference
Engine
Fiat 2.9L 3-cyl dieselReference
Fuel tank79.9 LReference
Engine44.7 kWReference
Fiat 8035.05Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.9 LReference
Bore/Stroke104 x 115 mmReference
Power44.7 kWReference
Fuel systemdirect injectionReference
Pre-heatingether injectionReference
Compression17:1Reference
Rated RPM2500Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speed synchromeshReference
12-speed mechanical shuttleReference
20-speed creeperReference
TypesynchromeshReference
Gears12 forward and 4 reverseReference
Clutch279.4mm dry discReference
Four gears (1-4) in three ranges (I-III) plus reverse range.Reference
Typemechanical shuttleReference
Gears12 forward and reverseReference
Four gears (1-4) in three ranges (I-III) with mechanical shuttle.Reference
TypecreeperReference
Gears20 forward and 8 reverseReference
PTO & Hydraulics
PTO (claimed)38.0 kWReference
Typeopen centerReference
Pressure186.3 barReference
Rear valves2 or 3Reference
Pump flow41.6 lpmReference
Rear TypeI/IIReference
Rear lift2245 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@2198Reference
Dimensions
2WD Wheelbase215 cmReference
4WD Wheelbase215 cmReference
Weight6292 to 6754 poundsReference
Front tire7.50-16Reference
2WD Rear tire16.9-30Reference
2WD Standard tires (ag)Front: 7.50-16. Rear: 16.9-30Reference
4WD Standard tires (ag)Front: 11.2-24. Rear: 16.9-30Reference
2WD Length330 cmReference
4WD Length343 cmReference
2WD Weight2854 kgReference
4WD Weight3063 kgReference
2WD Front tread147 to 189 cmReference
4WD Front tread162 to 195 cmReference
4WD Rear tread139 to 200 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps65Reference
Battery volts12Reference
Hesston 60-90 Height
2WD Hood148 cmReference
4WD Hood147 cmReference
2WD ROPS255 cmReference
4WD ROPS254 cmReference
Cab250 cmReference
Speeds
With 16.9-30 rear tires.Reference
With 18.4-30 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
