Tractor · 1990Unverified
Hesston 65-56
Hesston 65-56 — 56 Series · 60 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
60 hp
Weight
4900 to 5720 pounds
Hover a source tag to verify
Overview
DistributorHesstonReference
ManufacturerFiatReference
Utility tractorReference
Original price was $21,000 in 1990Reference
Two- or four-wheel driveReference
ROPS with canopy.Reference
Variants
65-56DT4WDReference
Engine
Fiat 3.6L 4-cyl dieselReference
Engine48.5 kWReference
Fiat 8045.06Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.6 LReference
Bore/Stroke100 x 115 mmReference
Power48.5 kWReference
Fuel systemdirect injectionReference
Compression17:1Reference
Rated RPM2500Reference
StarterelectricReference
Starter volts12Reference
Transmission
8-speed partially synchronizedReference
12-speed partially synchronizedReference
Typepartially synchronizedReference
Gears8 forward and 2 reverseReference
Four gears (1-4), plus reverse (R), in two ranges (I/II)Reference
Gears12 forward and 3 reverseReference
Four gears (1-4), plus reverse (R), in three ranges (I, II, and III).Reference
PTO & Hydraulics
PTO (claimed)44.7 kWReference
Rear TypeI/IIReference
Rear PTOindependentReference
Rear PTO Type540Reference
Dimensions
2WD Wheelbase216 cmReference
4WD Wheelbase212 cmReference
Weight4900 to 5720 poundsReference
Front tire7.50-16Reference
2WD Rear tire14.9-30Reference
2WD Standard tires (ag)Front: 7.50-16. Rear: 14.9-30Reference
4WD Standard tires (ag)Front: 9.5-24. Rear: 14.9-30Reference
2WD Length343 cmReference
4WD Length352 cmReference
4WD Ground clearance34 cmReference
2WD Ground clearance53 cmReference
2WD Front tread139 to 199 cmReference
4WD Front tread144 to 187 cmReference
Rear tread131 to 191 cmReference
2222 kgReference
Operating2594 kgReference
Ballasted3333 kgReference
Steering wheel149 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Hesston 65-56 Height
2WD Hood147 cmReference
4WD Hood144 cmReference
2WD ROPS231 cmReference
4WD ROPS231 cmReference
2WD Exhaust238 cmReference
4WD Exhaust237 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
