Tractor · 1984Unverified

Hesston 90-90

Name: Hesston 90-90
Brand: Hesston

Hesston 90-90 — 90 Series · 81 hp. Reference specifications; pending source verification.

The Hesston 90-90 is a tractor model with a rated output of 81 hp, placing it centrally within its class in terms of power. Produced from 1984 to 1988, the model features a 5-cylinder diesel liquid-cooled engine, which transmits power to all four wheels via a 15-speed gearbox. The listed weight of the Hesston 90-90 is 3284 kg, and it is designed for use on areas of approximately 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

81 hp

Weight

3284 kg

Catalogue coverage

Variants represented

Richest spec table

31 rows

Recorded power

81 hp

Recorded weight

3284 kg

Transmissions

15-speed

Production years

1984-1988

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

DistributorHesstonReference

ManufacturerFiatReference

Row-Crop tractorReference

Original price was $35,400 in 1988Reference

Two- or four-wheel driveReference

Engine

Fiat 4.9L 5-cyl dieselReference

Engine67.1 kWReference

FiatReference

dieselReference

5-cylinderReference

liquid-cooledReference

Displacement4.9 LReference

Power67.1 kWReference

Transmission

15-speedReference

20-speedReference

Gears15 forward and 3 reverseReference

Gears20 forward and 8 reverseReference

PTO & Hydraulics

PTO (claimed)60.4 kWReference

Typeopen centerReference

Valves2Reference

Pump flow43.9 lpmReference

Rear TypeIIReference

Rear lift2874 kgReference

Rear PTOindependentReference

Rear PTO Type540/1000Reference

Dimensions

Wheelbase245 cmReference

Weight3284 kgReference

Front tire10.00-16Reference

Rear tire18.4-34Reference

Ag front10.00-16Reference

Ag rear18.4-34Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
