Tractor · 1977Unverified
Hinomoto E14
Hinomoto E14 — Compact Utility tractor · 14 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
14 hp
Weight
1538 to 1650 pounds
Hover a source tag to verify
Overview
ManufacturerHinomotoReference
Compact Utility tractorReference
Built in JapanReference
Two- or four-wheel driveReference
Open operator station.Reference
Variants
E14D4WDReference
Engine
Toyosha 0.9L 2-cyl dieselReference
Engine10.3 kWReference
Toyosha S88Reference
dieselReference
2-cylinderReference
liquid-cooledReference
Displacement0.9 LReference
Bore/Stroke84 x 80 mmReference
Power10.3 kWReference
Rated RPM2300Reference
Starter volts12Reference
Transmission
6-speed gearReference
TypegearReference
Gears6 forward and 2 reverseReference
PTO & Hydraulics
Rear TypeIReference
Rear PTO Type547/875/1000Reference
Dimensions
Weight1538 to 1650 poundsReference
Front tire4.50-10Reference
Rear tire8-18Reference
Ag front4.50-10Reference
Ag rear8-18Reference
Ag rear7-24Reference
Length221 cmReference
Width103 cmReference
Height118 cmReference
2WD Weight697 kgReference
4WD Weight748 kgReference
Ground clearance27 cmReference
E14 Serial Numbers
Location:Serial number plate in front of the gear shift lever.Reference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
