The Hinomoto E16 is a compact tractor rated at 16 hp, one of the smaller options in its class. Manufactured between 1977 and 1979, this model features a 2-cylinder diesel liquid-cooled engine, which drives four-wheel drive through a 6-speed gearbox. The listed operating weight ranges from 1635 to 1760 pounds, and it is suitable for tasks covering approximately 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
16 hp
Weight
1635 to 1760 pounds
Catalogue coverage
Variants represented
2
Richest spec table
36 rows
Recorded power
16 hp
Recorded weight
741 kg
Transmissions
6-speed gear
Production years
1977-1979
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerHinomotoReference
Compact Utility tractorReference
Built in JapanReference
Two- or four-wheel driveReference
Manual steeringReference
Open operator station.Reference
Variants
E16D4WDReference
Engine
Toyosha 1.1L 2-cyl dieselReference
Engine11.8 kWReference
Toyosha S110Reference
dieselReference
2-cylinderReference
liquid-cooledReference
Displacement1.1 LReference
Power11.8 kWReference
Rated RPM2200Reference
Starter volts12Reference
Transmission
6-speed gearReference
TypegearReference
Gears6 forward and 2 reverseReference
PTO & Hydraulics
Rear TypeIReference
Rear PTO Type547/875/1000Reference
Dimensions
Weight1635 to 1760 poundsReference
Front tire4.00-12Reference
Rear tire8.3-24Reference
Ag front4.00-12Reference
Ag rear8.3-24Reference
Ag rear7-24Reference
Length236 cmReference
Width114 cmReference
Height127 cmReference
2WD Weight741 kgReference
4WD Weight798 kgReference
Ground clearance28 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
